Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
Input
cables
Output cables
WARNING: All the screws on the electrical input/output terminal block of
the inverter should be tightened using 13 in/lbs torque.
(*) IMPORTANT: In case of inverter without the Switch Box, follow the
same cabling approach for signal and communication cables as shown in fig.
15c
Fig. 15b – Complete cabling particular
Page 44 of 108
RS485
cables
Alarm
cable
Ground
cable
