Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
5.5.7.1

Address

This function is used to set addresses for communication of the single inverters
connected in the system on an RS485 line. You can assign numbers from 2 to 250.
Press UP and DOWN to scroll numbers.
If you do not want to manually set the address of each inverter, select the AUTO
function and they will be distributed automatically.
5.5.7.2

Display Set

This function is used to set display features:
1) Light: display light setting:
- Use the MODE key to set display backlighting.
Select the Mode item with the arrow, and press ENTER to open the relevant submenu.
shown on this screen:
ON: Light always on
OFF: Light always off
AUTO: Automatic light setting. It turns on every time a key is pressed and stays on for
30 seconds then gradually turns off.
- Use the INTENSITY key to set the intensity of backlighting from 0 to 9.
NEW ADDRESS
248
Light
Contrast
Buzzer
Mode
Intensity
ON
OFF
Auto
NEW ADDRESS
Auto
Page 73 of 108
AUTO
2
3
.....
.....
249
250
AUTO
