Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
Input channels
configuration
(1) The total input power shall not exceed the max. Recommended DC power
NOTE: If the input current supplied by the photovoltaic field connected to
the inverter is above the max. value and the input voltage is within the
allowed range, the inverter will not be damaged.
8.2

Output values

Description
Nominal output
power
Grid voltage,
maximum range
Grid voltage,
nominal
Grid voltage,
operating range as
per UL 1741
regulation
Grid frequency,
nominal
Grid frequency,
operating range as
per UL 1741
regulation
Nominal output
Two independent MPPT channels with shared negative
Value
PVI–3.0-OUTD
3000 W
183 to 304 Vac
277V single phase
or
240V split phase
(default)
or
208V single phase
(setting required)
88% to 110% of
nominal voltage
(211 to 264Vac
for V=240Vac)
60 Hz
59.3 to 60.5 Hz
10.8/12.5/14.4
poles or
Two channels in parallel
Value
PVI–3.6-OUTD
3600 W
183 to 304 Vac
277V single phase
or
240V split phase
(default)
or
208V single phase
(setting required)
88% to 110% of
nominal voltage
(211 to 264Vac
for V=240Vac)
60 Hz
59.3 to 60.5 Hz
13/15/17
Page 94 of 108
Value
PVI–4.2-OUTD
4200 W
183 to 304 Vac
277V single
phase or
240V split phase
(default)
or
208V single
phase
(setting required)
88% to 110% of
nominal voltage
(211 to 264Vac
for V=240Vac)
60 Hz
59.3 to 60.5 Hz
15.1/17.5/19.9
