KEY:
LED on
LED blinking
LED off
Any one of the above conditions
LEDs Status
green:
yellow:
1
red:
green:
yellow:
2
red:
green:
yellow:
3
red:
green:
yellow:
4
red:
green:
yellow:
5
red:
green:
yellow:
6
red:
green:
yellow:
7
red:
Operational Status
Aurora self-disconnection
during nighttime
Aurora initialization,
settings loading, and
waiting for grid check
Aurora is powering the
grid
System insulation device
faulty
Defect – fault!!!
Installation phase: Aurora
is disconnected from
grid.
Grid disconnection
Page 57 of 108
Remarks
Input voltage less than 90
Vdc at both inputs
It is in a transition status
while operating conditions are
being checked.
Standard machine operation
(search of max. power point
or constant voltage).
Ground leakage found
The fault can be inside or
outside the inverter. See the
alarm appearing on the LCD.
During installation, it refers to
set-up of the address for RS-
485 communication.
Indicates a missing grid
condition.
