Table 2-2
Diagnostic and status indicators
No. Name Meaning
6
X1
Diagnos-
tics
PWR
Power
CON
Connect
Error
ERR
CHR
Charging
106377_en_04
2.2
Diagnostic and status indicators
Figure 2-2
Diagnostic and status indicators
Color
Status
Reserved for future expansions
Green
On
Flashing
(1 Hz)
Yellow
On
Flashing
(1 Hz)
Red
On
Flashing
(1 Hz)
Blue
On
Flashing
(1 Hz)
Connections, indicators, configuration switches
S1
S2
PWR
CON
ERR
CHR
Description
Charging controller ready
Charging controller is starting up
Charging cable is connected to the charging station and the vehicle
Charging cable is connected to the charging station and locked
Error
Errors that originate at the vehicle or charging cable
Charging contactor closed
Vehicle connected, charging current ready, PWM signal switched
on, charging contactor open
6
11 / 68
