Table 9-3 Function assignment of output registers for the digital outputs
Value Function
25 Charging controller has detected a 13 A or 20 A connector at PP
26 Insufficient current carrying capacity of the charging cable
27 Charging controller switches the charging contactor ON
28 Cannot be used for this device
29 Locking active
30 Cannot be used for this device
31 Cannot be used for this device
32 Cannot be used for this device
33 Cannot be used for this device
34 Cannot be used for this device
35 Charging contactor monitoring triggered
36 Status D, vehicle rejected
37 Vehicle connected in status B or C or D
38 EV-RCM: Test and reset function
39 EV-RCM: Error (system error or residual current detected)
≥ 39 Not permitted
