EV Charge Control Basic
Table 9-2 Register assignment
Type Address Value
Hold- 4002 16 bits
ing
4006 16 bits
4007 16 bits
4008 16 bits
56 / 68
PHOENIX CONTACT
Access Memory
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read –
Function
Activating the locking function
Charging connector in the In-
frastructure Socket Outlet
Function activation for
charging contactor monitor-
ing. For charging contactor
monitoring via input CCR,
charging current adaptation
via input CCR must be deacti-
vated (register 4012 = 0)
Delay time between switching
off the charging contactor and
executing charging contactor
monitoring
Rejecting invalid charging
cable
Relevant for EV-CC-AC1-M3-
CBC-... only
Coding
Integer
If S1/DIP 3 = OFF:
0: Locking is performed automat-
ically when the vehicle is con-
nected (status B), unlocking is
performed if the vehicle is not de-
tected (status A).
(Default, if S1/DIP 3 = OFF, other
values have no effect)
If S1/DIP 3 = ON:
1: Locking upon ON signal at
input ML, unlocking if signal at
input ML = OFF
(Default, if S1/DIP 3 = ON)
2: Locking in the event of a
pulsed signal at input ML, unlock-
ing upon next pulse
3: Locking if value 1 is written to
register 20002. Unlocking if
value 0 is written.
Integer
0: Charging contactor monitoring
deactivated (default)
1: Charging contactor monitoring
by evaluating a force-guided N/C
contact at input CCR
Integer in ms
Default = 200 ms
Integer
If S1/DIP 4 = OFF
0: All charging cables permitted
If S1/DIP 4 = ON
1: 13 A charging cable is rejected
