Installing and operating the
AXC 1050 and AXC 1050 XC
controllers
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AXC 1050 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Phoenix Contact AXC 1050

Summary of Contents for Phoenix Contact AXC 1050

  • Page 1 Installing and operating the AXC 1050 and AXC 1050 XC controllers User manual...
  • Page 2 User manual Installing and operating the AXC 1050 and AXC 1050 XC controllers 2017-06-02 Designation: UM EN AXC 1050 (XC) Revision: Order No.: — This user manual is valid for: Designation As of version (HW) As of version (FW) Order No.
  • Page 3 How to contact us Internet Up-to-date information on Phoenix Contact products and our Terms and Conditions can be found on the Internet at: phoenixcontact.com Make sure you always use the latest documentation.
  • Page 4 The receipt of technical documentation (in particular user documentation) does not constitute any further duty on the part of Phoenix Contact to furnish information on modifications to products and/or technical documentation. You are responsible to verify the suitability and intended use of the products in your specific application, in particular with regard to observing the applicable standards and regulations.

  • Page 5: Table Of Contents

    Table of contents For your safety ...........................9 Intended use......................9 Modifications ......................9 Safety notes......................9 Notes on using the AXC 1050 XC controller in potentially explosive areas of zone 2 ......................11 From transport to unpacking ....................13 Transport ......................13 Storage........................13 Checking the delivery ..................13 Unpacking ......................14...
  • Page 6 The PROFINET controller/device function of the AXC 1050 (XC)......63 6.5.1 Activating the PROFINET controller/device function ......63 6.5.2 Integrating the AXC 1050 (XC) as a PROFINET controller ....66 6.5.3 Integrating the AXC 1050 (XC) as a PROFINET device .......67 Setting the real-time clock ...................71 Compiling after completing the bus topology ............71...
  • Page 7 8.11 Mode selector switch ..................123 8.12 Project-related system variables................123 8.13 System time.......................123 Web-based management (WBM) ..................124 Installing the WBM.....................124 Establishing a connection with the WBM ............124 Changing the language..................125 Areas and functions ...................125 9.4.1 "Information" area ................126 8482_en_03 PHOENIX CONTACT...
  • Page 8 12.2.3 Software .....................149 12.2.4 Documentation ...................149 Appendix ..........................150 Performing updates ...................150 Derating for the controller AXC 1050 XC ............152 Tested successfully: Use under extreme ambient conditions ......153 Appendix for document lists....................154 List of figures .....................154 List of tables ......................158 Index........................160...

  • Page 9: For Your Safety

    For your safety Intended use The AXC 1050 and AXC 1050 XC controllers are modular, small-scale controllers that can be used for smaller and medium-sized applications. The devices belong to the IP20 protec- tion class and are designed for use in closed control cabinets or control boxes (terminal boxes) with an IP54 degree of protection or higher.
  • Page 10 §§ 15 ff. AktG or German Stock Corporation Act (hereinafter collectively referred to as "Phoenix Contact") from all third-party claims that are made due to improper use. For the protection of networks for remote maintenance via VPN, Phoenix Contact offers the mGuard product series security appliances which you can find described in the latest Phoenix Contact catalog (phoenixcontact.net/products).

  • Page 11: Notes On Using The Axc 1050 Xc Controller In Potentially Explosive Areas Of Zone 2

    For your safety Notes on using the AXC 1050 XC controller in potentially explosive areas of zone 2 Approval in accordance with the 2014/34/EU directive II 3 G Ex nA IIC T4 Gc X WARNING: Explosion hazard Please make sure that the following notes and instructions are observed!
  • Page 12 AXC 1050 (XC) Installation in zone 2 Observe the specified conditions for use in potentially explosive areas. Install the device in a suitable approved housing (with at least IP54 protection according to EN 60529) that meets the requirements of EN 60079-15:2010. Pay attention to the requirements of EN 60079-14.

  • Page 13: From Transport To Unpacking

    Damaged packaging is an indicator of potential damage to the device that may have oc- curred during transportation. This could result in a malfunction. • Submit claims for any transport damage immediately, and inform the Phoenix Contact or your supplier as well as the shipping company without delay. •...

  • Page 14: Unpacking

    Bus base module AXL F BS BK – Supply plug AXL CN S/UL Unpacking The AXC 1050 (XC) is supplied in the packaging together with a packing slip with installa- tion instructions. • Read the complete packing slip carefully before unpacking the controller.

  • Page 15: Description Of The Axc 1050 (Xc)

    The AXC 1050 and AXC 1050 XC controllers have the same appearance. They only differ with regard to a function. In the following, the term controller or AXC 1050 (XC) is there- fore used in general. Where necessary, any differences are indicated accordingly.

  • Page 16: Components Of The Controller

    As of firmware version 3.00, the controller can be used as an IED (Intelligent Electronic De- vice) for communication in accordance with IEC 61850. You can find information on config- uration in the "IEC 61850 configuration of a Phoenix Contact IED" user manual. The user manual can be downloaded at phoenixcontact.net/products.
  • Page 17 Enabling/disabling the MRP client function USB driver In order to use the service interface of the controller, the "Phoenix Contact USB to UART Interface" driver must be installed. This must be selected explicitly when installing the AUTOMATIONWORX Software Suite. See also Section 6.1.
  • Page 18 The SD card is already formatted and is intended for use with Phoenix Contact devices. When you format the SD card, certain information on the SD card that is required for use with Phoenix Contact devices is lost. After formatting, you can no longer use the SD card to operate the controller.

  • Page 19: Possible Fields Of Application Of The Controller

    The total current consumption of all devices aligned on the controller must not exceed the maximum current that the controller supplies for the local bus (2 A). Ethernet 42 43 02 03 8482B001 Figure 3-2 Axioline F station with AXC 1050 controller 8482_de_03 PHOENIX CONTACT...

  • Page 20: The Axc 1050 (Xc) As A Profinet Controller In A Profinet Network

    AXC 1050 (XC) 3.3.2 The AXC 1050 (XC) as a PROFINET controller in a PROFINET network Figure 3-3 shows the example of an AXC 1050 as a PROFINET controller in a PROFINET network. PROFINET PROFINET 8482A020 Figure 3-3 PROFINET controller with the AXC 1050 as an example...

  • Page 21: The Axc 1050 (Xc) As A Profinet Device In A Profinet Network

    Description of the AXC 1050 (XC) 3.3.3 The AXC 1050 (XC) as a PROFINET device in a PROFINET network Figure 3-4 shows the example of an AXC 1050 as a PROFINET device in a PROFINET net- work. RUN/PROG DISPLAY MRESET RFC 470 PN 3TX LAN1.1...

  • Page 22: System Redundancy With Axc 1050 Or Axc 1050 Xc

    PROFINET ring network that is configured as redundant using the MRP Media Redundancy Protocol. In the example, the AXC 1050 controller operates as a PROFINET device with control function and is connected to the PROFINET network via a switch.
  • Page 23 (BACKUP/PRIMARY) may change depending on the redundancy status Infrastructure components (in the example: FL SWITCH SMCS ... managed switches) PROFINET device with control function (in the example: AXC 1050 with activated PROFINET device function and Phoenix Redundancy Layer) 8482_de_03...

  • Page 24: Connection And Operating Elements

    AXC 1050 (XC) Connection and operating elements Figure 3-6 Connection and operating elements of the controller (AXC 1050 and AXC 1050 XC) The controller consists of the following components: Bus base module Reset button Service interface (X4) Electronics module Ethernet interfaces (X1, X2) FE tab (X3), 2.8 mm, for optional connection to functional earth ground...

  • Page 25: Diagnostics And Status Indicators

    A PROFINET controller has established an active communica- tion connection to the AXC 1050 (XC) (PROFINET device) or the function of the PROFINET device is switched off. No PROFINET communication (no link status at the Ethernet in- terfaces).
  • Page 26 Color Meaning State Description nation AXC 1050 (XC) concurrently operates as a PROFINET controller and device The AXC 1050 (XC) (PROFINET controller) has established an active communication connection to each configured PROFINET device and a PROFINET controller has established Status of...
  • Page 27 Description of the AXC 1050 (XC) Table 3-1 Diagnostics and status indicators of the controller Desig- Color Meaning State Description nation AXC: Axioline F diagnostics Run: The Axioline F station is ready for operation; communication Green on within the Axioline F station is OK.
  • Page 28 AXC 1050 (XC) Table 3-1 Diagnostics and status indicators of the controller Desig- Color Meaning State Description nation PWR: supply voltage (communications power U 24 V communications power feed-in not present or too low. Green Logic 24 V communications power feed-in present.

  • Page 29: Mode Selector Switch

    Description of the AXC 1050 (XC) Mode selector switch The mode selector switch is used to define the operating state of the controller. The RUN/PROG and STOP positions have a latching function and the MRESET position has a pushbutton function. After releasing the switch in the MRESET position, it returns to the STOP position.

  • Page 30: Reset Button (Concealed)

    AXC 1050 (XC) Reset button (concealed) 8482A006 Figure 3-9 Reset button (1, concealed) The reset button on the controller can only be operated with a pointed item (e.g., a pen) and is therefore protected against accidental activation. If the reset button is actuated during operation, the controller is restarted. Furthermore, if you carry out a voltage reset concurrently as you press the reset button, this resets the con- troller to its default settings.

  • Page 31: Parameterization Memory

    The SD card is already formatted and is intended for use with Phoenix Contact devices. When you format the SD card, certain information on the SD card that is required for use with Phoenix Contact devices is lost. After formatting, you can no longer use the SD card to operate the controller.

  • Page 32: Internal Basic Circuit Diagram

    LNK ACT RJ45 LNK ACT Reset μC Local bus 3.3 V 24 V Figure 3-10 Internal basic circuit diagram (AXC 1050 (XC)) Key: μC Microprocessor Transmitter Service interface (Micro-USB type B) Real-time clock 3.3 V Reset button Power supply unit...

  • Page 33: Communication Paths

    Description of the AXC 1050 (XC) 3.10 Communication paths The following communication paths are available on the controller (see Figure 3-11): 2 x Ethernet X1/X2: 10/100Base-T(X) (switched internally) Service inter- A free USB interface on your PC is connected directly to the con- face (Micro- troller.

  • Page 34: Ethernet

    AXC 1050 (XC) 3.10.1 Ethernet Two Ethernet interfaces (X1/X2) are available on the controller for connecting the Ethernet network. The Ethernet network is connected via RJ45 sockets. • Use an Ethernet cable which corresponds to CAT5 of IEEE 802.3 at least.

  • Page 35: Service Interface (Micro-Usb Type B)

    3.10.2 Service interface (Micro-USB type B) In order to use the service interface of the controller, the "Phoenix Contact USB to UART Interface" driver must be installed (see Section Section 6.1). In addition to providing the Ethernet interface, the service interface enables communication with the controller from a PC.

  • Page 36: Supply Plug

    AXC 1050 (XC) 3.11 Supply plug Figure 3-14 Terminal points for the supply voltage (communications power U Terminal point assign- ment Table 3-3 Terminal point assignment of the supply connector Terminal point Color Assignment a1, a2 24 V DC (U...

  • Page 37: Mounting Hardware

    The controller is automatically grounded (FE) when it is snapped onto a grounded DIN rail. On the back of the controller there are two FE springs that make contact with the DIN rail when the controller is placed on the DIN rail. Figure 4-1 Placing the module vertically 8482_en_03 PHOENIX CONTACT...

  • Page 38: Basics

    AXC 1050 (XC) Basics Mounting location The controller fulfills the IP20 degree of protection and is designed for use in closed control cabinets or control boxes (terminal boxes) with IP54 degree of protection or higher. Mounting on a DIN rail The controller is mounted on a 35 mm standard DIN rail without any tools using the bus base module.

  • Page 39: Horizontal (A) And Vertical (B) Mounting Position

    Mount end brackets on both sides of the Axioline F station. They ensure that the Axioline F station is correctly mounted. End brackets secure the station on both sides and keep it from moving from side to side on the DIN rail. Phoenix Contact recommends using the following end brackets:...

  • Page 40: Structure Of An Axioline F Station

    Structure of an Axioline F station Figure 4-3 shows an example structure of an Axioline F station: Figure 4-3 Structure of an Axioline F station with AXC 1050 controller Key: DIN rail End bracket (e.g., CLIPFIX 35-5; Order No. 3022276)

  • Page 41: Mounting The Controller

    Place the controller vertically on the first bus base module until it snaps into place with a click. Make sure that the device plug for the bus base connection is situated above the cor- responding socket on the bus base module. Figure 4-5 Snapping on the controller 8482_en_03 PHOENIX CONTACT...

  • Page 42: Inserting The Sd Card

    AXC 1050 (XC) Inserting the SD card The controller has an SD card holder with push/push technology. • Gently push the SD card into the SD card holder until it engages with a click in the SD card holder. >Click<...

  • Page 43: Connecting And Wiring Hardware

    [ ] V [ ] A 1.1 x I 2.4 x I 1.5 x I 6219B070 6219B071 Figure 5-1 Overload range with fall-back characteristic Figure 5-2 Overload range without fall-back charac- curve teristic curve 8482_en_03 PHOENIX CONTACT...

  • Page 44: Connecting The Power Supply

    AXC 1050 (XC) 5.1.2 Connecting the power supply Observe the notes in Section 3.11 when assembling the plug for the supply voltage. • Strip 8 mm off the cable. • Fit a ferrule to the cable, if required. If you are using ferrules, use them in accordance with the specifications in the UM EN AXL F SYS INST user manual.

  • Page 45: Figure 5-5 Connecting The Supply Plug

    D LEDs are permanently on. The controller is now fully initialized. If the LEDs do not light up or start flashing, there is a serious fault on the controller. • In this case, please contact Phoenix Contact. 8482_en_03 PHOENIX CONTACT...

  • Page 46: Connecting Ethernet

    AXC 1050 (XC) Connecting Ethernet • Connect the Ethernet network to the RJ45 sockets. 8482B008 Figure 5-6 Connecting Ethernet Connecting USB cable • Make sure that the controller is supplied with power (see Section "Connecting the pow- er supply" on page 44) and in the RUN operating state.

  • Page 47: Startup

    AXC 1050 (XC) will be detected as a USB device under Windows Figure 6-1 Selecting the USB driver If, after installation, the AXC 1050 (XC) is not automatically detected as a USB device under ® Windows , repeat the installation process and make sure that the "USB to UART Interface"...

  • Page 48: Creating A New Project

    Before you can configure the settings described in the following sections, you have to create a new project in the software. • In the "New Project" dialog, select the "AXC 1050 ..." template according to the version of the controller you are using. •...

  • Page 49: Assigning The Ip Address For The Controller

    "Bus Structure" window. You can assign these settings to the controller via the Discovery and basic Configuration Protocol (DCP) if you select the relevant functions in the "IP Assignment" tab (see Figure 6-4 on page 51). • Adapt the IP address settings to your application, if necessary. 8482_en_03 PHOENIX CONTACT...

  • Page 50: Figure 6-3 Ip Address Settings Of The Controller (Axc 1050)

    In the "Device Details" window, switch to the "IP Settings" tab (see Figure 6-3). • Check the displayed IP address settings. • Adapt the IP address settings if necessary. Figure 6-3 IP address settings of the controller (AXC 1050) PHOENIX CONTACT 8482_en_03...

  • Page 51: Figure 6-4 "Ip Assignment" Dialog: Dcp Devices Are Accessible In The Network

    (A) to the selected device (B). If you have not selected a device from the list, the software will notify you of this. The successful IP address assignment is displayed in the "Device Details" window (see A and B in Figure 6-5). 8482_en_03 PHOENIX CONTACT...

  • Page 52: Bootp Server

    A corresponding IP address and subnet mask have been assigned in PC Worx (Express) for the MAC address. Once the IP data has been transferred to the AXC 1050 successfully, PC Worx (Express) sends a corresponding acknowledgment message. Communication path and IP addresses/BootP Please note: –...

  • Page 53: Figure 6-6: Entering Ip Address Settings

    In the Windows Control Panel, check the settings for your PC network adapter. – If necessary, adjust these settings so that the AXC 1050 can be accessed in your net- work via the IP address used. • If your network does not permit the use of the IP address used, adjust the settings in the project information accordingly (see Figure 6-2 on page 48).

  • Page 54: Figure 6-7: "Extras, Bootp/Snmp/Tftp-Configuration

    AXC 1050 (XC) Establishing a connection • Connect the controller with your PC via an Ethernet cable. Activating BootP • In the PC Worx (Express) menu bar, select the "Extras, BootP/SNMP/TFTP-Configuration..." menu. Figure 6-7 "Extras, BootP/SNMP/TFTP-Configuration..." menu • Click on the "Activate BootP" button (A in Figure 6-8).

  • Page 55: Figure 6-9: Message Window Following Bootp

    In the "Device Details" window, select the "Communication" tab. • Click the "Test" button to test the assigned network settings. A successful communication test is indicated by the text "Host Type: AXC 1050" displayed with a green background. Figure 6-10...

  • Page 56: Assigning The Ip Address Via The Usb Interface

    PC via the USB interface. In order to use the USB interface of the AXC 1050 (XC), the "Phoenix Contact USB to UART Interface" driver must be installed; see Section 6.1 on page 47.

  • Page 57: Figure 6-12: "Settings Communication Path" Dialog Box

    (voltage reset). • In "Device Details", select the "Ethernet" setting under "Extended Settings". • In the "Activate Network Settings" area, click on the "Restart Controller" button. Figure 6-14 Activate Network Settings: Restart Controller 8482_en_03 PHOENIX CONTACT...

  • Page 58: Figure 6-15: Activating The Network Settings: Service Executed Successfully

    In the "Device Details" window, select the "Communication" tab. • Click the "Test" button to test the assigned network settings. A successful communication test is indicated by the text "Host Type: AXC 1050" displayed with a green background. Figure 6-16...

  • Page 59: Dynamic Host Configuration Protocol (Dhcp)

    In the "Settings Communication Path" dialog box, confirm the suggested IP address or the one you have set according to your application with "OK" to transfer the settings to the controller. Successful execution of the service is displayed in the status window. 8482_en_03 PHOENIX CONTACT...
  • Page 60 AXC 1050 (XC) Restarting the controller To apply the settings in the controller, the controller must be restarted. • In the "Device Details" window, select the "Ethernet" setting under "Extended Settings". • In the "Activate Network Settings" area, click on the "Restart Controller" button.

  • Page 61: Reading Axioline F

    When the "Re-insert all modules" check box is activated, modules that have already been configured are also read again. The previously configured bus structure is overwritten. Figure 6-19 "Read Axioline" dialog: Axioline F modules that have not yet been read in 8482_en_03 PHOENIX CONTACT...

  • Page 62: Figure 6-20 Read-In Axioline F Devices

    AXC 1050 (XC) • Activate the "Re-insert all modules" check box. • Select all connected Axioline F modules. • Click the "OK" button to read in the selected Axioline F modules. • Acknowledge the "Read Axioline – Do you want to delete all configured Axioline mod- ules and accept the connected modules?"...

  • Page 63: The Profinet Controller/Device Function Of The Axc 1050 (Xc)

    – How to activate or deactivate the PROFINET controller/device function in PC Worx (Express). – How to integrate the AXC 1050 (XC) into PC Worx as a PROFINET controller and/or PROFINET device. 6.5.1 Activating the PROFINET controller/device function The PROFINET activation procedure is identical in PC Worx and PC Worx Express.

  • Page 64: Figure 6-22 Profinet Activation: Sending Settings

    AXC 1050 (XC) • Click on the "Send" button. Figure 6-22 PROFINET activation: sending settings • In the "Settings Communication Path" dialog box, confirm the suggested IP address or the one you have set according to your application with "OK".

  • Page 65: Figure 6-25 Activate Network Settings: Restart Controller

    Successful execution of the service is displayed in the status window. Figure 6-27 Activating the network settings: service executed successfully The BF LED flashes following successful execution of the service. The AXC 1050 (XC) can now be read in as a PROFINET device in a PC Worx project. 8482_en_03...

  • Page 66: Integrating The Axc 1050 (Xc) As A Profinet Controller

    Adapt the IP address settings if necessary (see Section 6.3). • Configure your bus structure: – Read in the Axioline F devices aligned on the AXC 1050 (XC) (see Section 6.4). – Read in the PROFINET devices connected to the AXC 1050 (XC) (see Section 6.5.3).

  • Page 67: Integrating The Axc 1050 (Xc) As A Profinet Device

    255.255.255.0 – PROFINET device name: AXC-10501 You can read in the AXC 1050 (XC) as a PROFINET device if the following requirements have been fulfilled: – The PROFINET device function of the AXC 1050 (XC) is activated (seeSection 6.5.1). –...

  • Page 68: Figure 6-28 Bus Structure: Profinet Context Menu "Read Profinet

    Figure 6-28 Bus Structure: PROFINET context menu "Read PROFINET..." The "Read PROFINET" dialog that opens shows the PROFINET devices that are available in the connected network. Figure 6-29 "Read PROFINET" dialog • Select the AXC 1050 (XC). PHOENIX CONTACT 8482_en_03...

  • Page 69: Figure 6-30 "Select Profinet Device Description" Dialog

    Repeat this procedure until you have inserted all of the PROFINET devices in your net- work in the project. • Then click on the "Close" button to close the "Read PROFINET" dialog. The inserted PROFINET device(s) is/are displayed in the "Bus Structure" window. 8482_en_03 PHOENIX CONTACT...

  • Page 70: Figure 6-31 Axc 1050 (Xc) Inserted As A Profinet Device

    The process data of the PROFINET device is displayed in "Device Details" in the "Process Data" tab. Figure 6-32 AXC 1050 (XC) as a PROFINET device: Process Data The AXC 1050 (XC) is now available as a PROFINET device in the PC Worx project. PHOENIX CONTACT 8482_en_03...

  • Page 71: Setting The Real-Time Clock

    Compiling after completing the bus topology • When compiling a project for the first time, select the "Rebuild Project" entry from the "Build" menu. You can use the "Make" entry from the "Build" menu for additional compiling procedures. 8482_en_03 PHOENIX CONTACT...

  • Page 72: Using The Sd Card As The Main Memory Or Additional Memory

    AXC 1050 (XC) Using the SD card as the main memory or additional memory The function is available for controllers with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. The SD card can be used as main or as additional memory.

  • Page 73: Figure 6-34: Setting The Sd Card As The Main Memory

    Under "Settings", select the "Preferably, use the external SD card as main memory" set- ting in the drop-down list. • Click on the "Send" button (hidden by the drop-down list in Figure 6-34) to send the set- ting to the controller. • Restart the controller. 8482_en_03 PHOENIX CONTACT...

  • Page 74: Additional Memory

    The function is available for controllers with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. WARNING: Explosion hazard AXC 1050 XC In potentially explosive areas, the SD card must not be used as additional memory. Use the SD card as main memory only.

  • Page 75: Figure 6-35 Setting The Sd Card As The Additional Memory

    Under "Settings", select the "Use external SD card as additional memory" setting in the drop-down list. • Click on the "Send" button (hidden by the drop-down list in Figure 6-35) to send the set- ting to the controller. • Restart the controller. 8482_en_03 PHOENIX CONTACT...

  • Page 76: Figure 6-36 "Sddisk" Directory On The Sd Card

    AXC 1050 (XC) 6.8.2.1 Using the SD card as the memory for log files You can use the SD card as the memory for log files. The content of the "cfroot" directory is shown in the "sddisk" directory on the SD card. You can view the directories on the SD card if you access the Inline controller via FTP (see Section 7.3).

  • Page 77: Figure 6-38 Opening The "Logfile.txt" File Using The File_Open Function Block

    Figure 6-38 shows a FILE_OPEN function block for opening the ''Logfile.txt" file in the "\sddisk\Logfile" directory. Figure 6-38 Opening the "Logfile.txt" file using the FILE_OPEN function block • In the "Variable Properties" dialog (shown on the right in Figure 6-38) always enter the complete path and the file name. 8482_en_03 PHOENIX CONTACT...

  • Page 78: Creating The Program And Variables

    AXC 1050 (XC) Creating the program and variables • Create the program. • Create all necessary variables For additional information on creating a program and creating variables, refer to the PC Worx (Express) software online help or quick start guide.

  • Page 79: Useful Information About The Pc Worx Software

    In the user management area for Diag+ 2, you can enable or disable individual functions for specific users. You can open the user management area via "Start, All Pro- grams, Phoenix Contact, AUTOMATIONWORX Software Suite <Version>, Tools, DIAG+ Administration".

  • Page 80: Figure 7-2 Communication Path In Diag+ 2: Axc 1050 (Xc) Controller Found

    AXC 1050 (XC) After completing the scan process successfully, the AXC 1050 (XC) controller will display the following: Figure 7-2 Communication path in Diag+ 2: AXC 1050 (XC) controller found • Make sure that "Axioline Modules" is set as the device type in the "Device Representa- tion"...

  • Page 81: Figure 7-4 Diagnostic View: Selecting "Axioline Diagnostic

    At the top of the "Diag+ 2" dialog box, select "Axioline Diagnostic" as the view. Figure 7-4 Diagnostic view: selecting "Axioline Diagnostic" Diag+ 2 switches to the diagnostic view of the connected Axioline F system configured in PC Worx. Figure 7-5 Diag+ 2: "Axioline Diagnostic" 8482_en_03 PHOENIX CONTACT...

  • Page 82: Figure 7-6 Axl Di 32/1-Me Axioline F Module: No Error

    AXC 1050 (XC) Figure 7-6 shows the diagnostic view of an Axioline F module that is operating without er- rors. Figure 7-6 AXL DI 32/1-ME Axioline F module: No error Any errors that occur are diagnosed by Diag+ 2 and displayed.

  • Page 83: Figure 7-7 Axl Di 32/1-Me Axioline F Module: Supply Voltage Failure

    Useful information about the PC Worx software Figure 7-7 shows the diagnostic view of an Axioline F module with supply voltage that is not present. Figure 7-7 AXL DI 32/1-ME Axioline F module: Supply voltage failure 8482_en_03 PHOENIX CONTACT...

  • Page 84: Figure 7-8 Axc 1050 Controller - Peripheral Fault

    Figure 7-8 shows the failure of the supply voltage for the Axioline F AXL DI 32/1-ME module at the selected controller. Figure 7-8 AXC 1050 controller – Peripheral fault Diagnostics can be used to identify the error in your application. PHOENIX CONTACT...

  • Page 85: Figure 7-9: Controller Context Menu

    If you have opened Diag+ 2 as standalone software using the "Start, All Programs, Phoenix Contact, AUTOMATIONWORX Software Suite <Version>, Diag+ 2.xx" menu, in some cases not all entries in the context menu will be shown to you. In these cases, you do not have the required user rights.

  • Page 86: Applying The Ip Address Immediately

    AXC 1050 (XC) Applying the IP address immediately The function is available for the AXC 1050 (XC) with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. When assigning the IP address via BootP (see Section 6.3.2) and manually assigning the IP address via USB (see Section 6.3.3), the IP address settings only take effect after a con-...

  • Page 87: Parameterization Memory And Internet Explorer

    The FTP functionality must be activated in Internet Explorer (see Section 7.3.1). • Open the Bus Configuration Workspace. • Select the controller in the "Bus Structure" window (here: "AXC 1050"). • Select the "Extended Settings" tab in the "Device Details" window. ® •...

  • Page 88: Activating The Ftp Functionality Of Internet Explorer

    AXC 1050 (XC) The file structure, which is stored on the parameterization memory, is displayed in the Inter- ® net Explorer window that opens. Data may only be copied or deleted on the parameterization memory. Do not edit any files ®...

  • Page 89: Activating/Deactivating The Ftp Server

    ETH_SRV_FTP_ACTIVE system variable. Value range for the CPU_Set_Value_Request service: Code 02CB Var Count Var ID 0172 Value 0000 Deactivate FTP server 0001 Activate FTP server Figure 7-12 Deactivate FTP server 8482_en_03 PHOENIX CONTACT...

  • Page 90: Creating, Renaming Or Deleting Via The Ftp Directory

    7.3.3 Creating, renaming or deleting via the FTP directory The function is available for the AXC 1050 (XC) with firmware versions ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. You can create directories on the internal parameterization memory or the SD card or delete directories that have already been created.

  • Page 91: Restricting Ftp Access

    Useful information about the PC Worx software 7.3.4 Restricting FTP access The function is available for the AXC 1050 (XC) with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. To prevent unauthorized FTP access to the parameterization memory (internal parameter- ization memory or SD card), you can define a user name (max.

  • Page 92: Figure 7-14 Defining A User Name And Password For Ftp Access

    AXC 1050 (XC) Example: User name "USER" (length "04"), password "PASS" (length "04") Charac- ASCII Charac- ASCII For the example shown, the ASCII characters "0455 5345 52" (length of the user name fol- lowed by the individual characters of the user name) must be entered for the user name "USER"...

  • Page 93: Figure 7-15: Removing The User Name And Password For Ftp Access

    To remove the user name and password, proceed as described above but under "CPU Re- and password quest" enter the value "0000" for (* Value ... *); see Figure 7-15. Figure 7-15 Removing the user name and password for FTP access 8482_en_03 PHOENIX CONTACT...

  • Page 94: Web Server

    AXC 1050 (XC) Web server The AXC 1050 (XC) controller has a web server that can communicate via HTTP or HTTPS. With its visualization software, you can use the web server to visualize control variables, for example, in a web browser.

  • Page 95: Using The Hypertext Transfer Protocol Secure (Https)

    Phoenix Contact web panels with the AXC 1050 (XC). • When using Phoenix Contact web panels with the AXC 1050 (XC), establish an HTTP connection to prevent communication interference. Security certificates from the web server are always accepted by the controller without be- ing verified.

  • Page 96: Sending E-Mails Securely

    Web server: using HTTPS Sending e-mails securely The function is available for the AXC 1050 (XC) with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. You can use the SMTPS method (e-mailing via SMTP with SSL/TLS) for secure e-mailing.

  • Page 97: Activating/Deactivating Specific Ports

    Useful information about the PC Worx software Activating/deactivating specific ports The function is available for the AXC 1050 (XC) with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. Depending on your application, it may be necessary to activate or deactivate specific ports.

  • Page 98: Activating/Deactivating The Journaling Function

    AXC 1050 (XC) Activating/deactivating the journaling function The file system of the parameterization memory supports the journaling function. As a re- sult, voltage failures during write processes do not destroy the file system; however, the ac- cess speed becomes slower.

  • Page 99: Activating/Deactivating Or Reading The Mrp Client Function

    The Media Redundancy Protocol (MRP) can be used via the Ethernet interfaces of the AXC 1050 (XC) controller. The controller supports the MRP client function. This function is disabled by default. If the function is enabled, it remains enabled after the supply voltage is switched off and on.

  • Page 100: Event Task For The "Power Failure" Event

    AXC 1050 (XC) Event task for the "Power failure" event If the supply voltage fails in the application, it may make sense to start data backup auto- matically, e.g., to protect the application. In this case, an event task can be defined in PC Worx, which is started in the case of the "Power failure"...

  • Page 101: Figure 7-22 "Task Settings For 'Powerof'" Dialog

    Disable the "Enable Watchdog" check box. • Click on "OK" to save your entries. Figure 7-22 "Task settings for 'PowerOf'" dialog The previously defined "PowerOf" event task is displayed in the "Project Tree Window". Figure 7-23 "PowerOf" event task 8482_en_03 PHOENIX CONTACT...

  • Page 102: Function Blocks For Handling Files On The Parameterization Memory

    AXC 1050 (XC) 7.10 Function blocks for handling files on the parameterization memory The function blocks enable access to files on the internal parameterization memory or the SD card of the controller. Some of the blocks support multiple instantiation. This means that it is possible to work with a number of different files within the same project.

  • Page 103: Function Blocks For Ethernet Communication

    As of firmware Ethernet connections to other version version communication partners (maxi- (HW) (FW) mum) IEC-61131-5 AXC 1050 (XC) TCP/IP 1.00 UDP/IP Table 7-2 Overview of the IP communication blocks Function block Short description IP_CONNECT Establishes a connection between two communication partners.

  • Page 104: Eth Communication Blocks In Accordance With Ieee 802.3

    7.11.2 ETH communication blocks in accordance with IEEE 802.3 The function is available for the AXC 1050 (XC) with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. ETH communication blocks can be used to establish communication via all Ethernet proto- cols.

  • Page 105: Outputs Of The Eth_Send Function Block

    Error codes of the "ADD_ERROR" input/output (ERROR output = TRUE) Value Description 0x01 ERR_ADDE_FB_ETH_PDU_INVALID_TYPE Incorrect data type at the ETH_PDU_DATA input/output. ARRAY data type required 0x02 ERR_ADDE_FB_ETH_PDU_NO_BYTE_ARRAY_TYPE Incorrect data type at the ETH_PDU_DATA input/output. Permissible data type: ARRAY [0...1517] OF BYTE 8482_en_03 PHOENIX CONTACT...

  • Page 106: Figure 7-25: Eth_Recv Function Block

    AXC 1050 (XC) Table 7-6 Error codes of the "ADD_ERROR" input/output (ERROR output = TRUE) Value Description 0x03 ERR_ADDE_FB_ETH_PDU_INVALID_SIZE Invalid Ethernet frame length at the ETH_PDU_DATA input/output. Permissible length: 18 ... 1518 Bytes 0x04 ERR_ADDE_FB_ETH_LEN_INVALID The Ethernet telegram length input at the ETH_PDU_LEN input is larger than the buffer storage unit of the ETH_PDU_DATA input/output.

  • Page 107: Outputs Of The Eth_Recv Function Block

    Incorrect data type at the ETH_PDU_DATA input/output. ARRAY data type required 0x02 ERR_ADDE_FB_ETH_PDU_NO_BYTE_ARRAY_TYPE Incorrect data type at the ETH_PDU_DATA input/output. Permissible data type: ARRAY [0...1517] OF BYTE 0x03 ERR_ADDE_FB_ETH_PDU_INVALID_SIZE Invalid Ethernet frame length at the ETH_PDU_DATA input/output. Permissible length: 18 ... 1518 Bytes 8482_en_03 PHOENIX CONTACT...
  • Page 108 AXC 1050 (XC) Table 7-10 Error codes of the "ADD_ERROR" input/output (ERROR output = TRUE) Value Description 0x04 ERR_ADDE_FB_ETH_LEN_INVALID The length of the Ethernet telegram length at the ETH_PDU_LEN output is larger than the buffer storage unit of the ETH_PDU_DATA input/output.

  • Page 109: Functional Blocks For Axioline F

    Axioline F local bus. Table 7-12 AX_CONTROL function block Function block Short description AX_CONTROL Sends firmware services to the Axioline F master The function block is described in the PC Worx (Express) online help. 8482_en_03 PHOENIX CONTACT...

  • Page 110: Function Block For Utc

    7.13 Function block for UTC The function is available for the AXC 1050 (XC) with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. The GET_UTC_TIMESTAMP function block enables you to query the coordinated universal time UTC.

  • Page 111: Ip_Info Function Block

    (ERROR output = TRUE) 7.14 IP_INFO function block The function is available for the AXC 1050 (XC) with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. The IP_INFO function block provides information about the current communication partner (IP address of the communication partner, port number, and communication protocol used).

  • Page 112: Alignment

    AXC 1050 (XC) 7.15 Alignment The alignment of the data elements in the controller memory can result in "data gaps" when storing data in the memory. The compiler automatically fills these gaps with padding bytes during the compilation process in order to prevent incorrect processing.

  • Page 113: Figure 7-27: Example Programming

    Struct1 receives a padding byte after the ByteElement so that the WordElement is at a WORD address (address that can be divided by two leaving no remainder). The alignment of the overall structure is based on the data type used with maximum alignment. In this case, the WordElement specifies the alignment. 8482_en_03 PHOENIX CONTACT...
  • Page 114 AXC 1050 (XC) The size of Struct2 is calculated based on the elements used and the resulting alignment. The corresponding number of padding bytes is inserted so that the size of the data type with the value of the alignment can be divided by two leaving no remainder (data type size mod- ulo alignment = 0).

  • Page 115: System Variables And Status Information

    Axioline F local bus is ready to operate. AXIO_DIAG_STATUS_REG_SYSFAIL BOOL The Axioline F local bus switches to the SYSFAIL state when the controller is in the STOP state or there is no pro- gram present on it. 8482_en_03 PHOENIX CONTACT...

  • Page 116: Diagnostic Parameter Register

    AXC 1050 (XC) Diagnostic parameter register The diagnostic parameter register provides additional information on the error indicated in the diagnostic status register. The error code is stored in the diagnostic parameter register and the error location in the extended diagnostic parameter register. The error location is stored as a slot number.

  • Page 117: Profinet System Variables

    (low-priority maintenance alarm) for the ac- tive connection. The PROFINET device can be identified using the RALRM diagnostic block. PNIO_FORCE_FAILSAFE BOOL All PROFINET devices are prompted to set their configured substitute values. PNIO_CONFIG_STATUS WORD Configuration status of the PROFINET controller 8482_en_03 PHOENIX CONTACT...

  • Page 118: Profinet System Variables (Profinet Device Function)

    The higher-level PROFINET controller has established the connection Information indicating whether a connection exists and cy- clic data is being exchanged between the PROFINET controller and PROFINET device (AXC 1050 (XC)) and whether the last frame received contains valid data. PND_S1_OUTPUT_STATUS_GOOD BOOL...

  • Page 119: Applicative System Redundancy

    Bit 3: Not supported; configuration parameter (RESET_ENGINEERING_PARAMETER) Bit 4: Not supported; all saved parameters (RESET_ALL_PARAMETER) Bit 5 ... 7: Reserved Bit 8: Not supported; all saved parameters in the PROFINET controller/device (RESET_DEVICE) Bit 9: Not supported; firmware (RESET_FIRMWARE) 8482_en_03 PHOENIX CONTACT...

  • Page 120: Iec-61131 Runtime System

    AXC 1050 (XC) IEC-61131 runtime system There is a separate group of system variables for the IEC-61131 runtime system. Table 8-5 System variables of the IEC-61131 runtime system System variable Type Meaning PLCMODE_ON BOOL PLC status ON: The runtime system on the controller is ready to operate.

  • Page 121: Control Processor

    The system variable in Table 8-7 shows status information regarding the control processor of the controller. Table 8-7 System variable of the control processor for displaying state information System variable Type Meaning COP_CPU_LOAD_WARNING BOOL The control processor is approaching its processor capacity limit. 8482_en_03 PHOENIX CONTACT...

  • Page 122: Ethernet Interfaces

    System variable of the SD card System variable Type Meaning FLASHCARD_PRESENT BOOL Phoenix Contact SD card intended for use with AXC 1050 (XC) is inserted. Energy storage, real-time clock Table 8-10 System variables of the energy storage and real-time clock System variable...

  • Page 123: Mode Selector Switch

    System time Table 8-14 System variables of the system time System variable Type Meaning RTC_HOURS System time (hours) RTC_MINUTES System time (minutes) RTC_SECONDS System time (seconds) RTC_DAY System time (day) RTC_MONTH System time (month) RTC_YEAR System time (year) 8482_en_03 PHOENIX CONTACT...

  • Page 124: Web-Based Management (Wbm)

    AXC 1050 (XC) Web-based management (WBM) The WBM is available for the AXC 1050 (XC) with a firmware version ≥ 3.00 from AUTOMATIONWORX Software Suite 2017 Version 1.84 and later. In the web-based management (WBM), you can access static and dynamic controller infor- mation and modify certain controller settings.

  • Page 125: Changing The Language

    Click the "Deutsch" or "English" link to change the language. The WBM then immediately switches to the desired language. Areas and functions The WBM is split into the following areas: – "Information" – "Diagnostics" – "Administration" – "WebVisu" 8482_en_03 PHOENIX CONTACT...

  • Page 126: Information" Area

    AXC 1050 (XC) 9.4.1 "Information" area This area includes general device information. 9.4.1.1 "General Data" page On the "General Data" page, you will find general details on the device, e.g., hardware and firmware versions and the order number as well as manufacturer details.
  • Page 127 Web-based management (WBM) 9.4.1.2 "Technical Data" page The most important technical data for the controller is summarized on the "Technical Data" page. Figure 9-3 "Technical Data" page 8482_en_03 PHOENIX CONTACT...
  • Page 128 AXC 1050 (XC) 9.4.1.3 "Diagnostic Indicators" page On the "Diagnostic Indicators" page, you will find a description of the LEDs and their possi- ble states. Figure 9-4 "Diagnostic Indicators" page PHOENIX CONTACT 8482_en_03...

  • Page 129: Diagnostics" Area

    On the "Controller" page, you will find a brief description of the current LED indicators of the controller during the runtime. If there is an error in the controller, an error code and error lo- cation are displayed. Figure 9-5 "Controller" page 8482_en_03 PHOENIX CONTACT...
  • Page 130 AXC 1050 (XC) 9.4.2.2 "Local bus" page All connected Axioline F local bus devices are displayed in an overview on the "Local bus" page. If you select an Axioline F local bus device, general specifications and diagnostic in- formation are displayed for the Axioline F local bus device ("Module Information" view).
  • Page 131 In the "Module Information" view, in addition to general information on the selected Axioline F module (e. g. hardware/firmware version, order number, etc.), you will find user- defined information. If there is an error in the Axioline F module, diagnostic information on the error is displayed. 8482_en_03 PHOENIX CONTACT...
  • Page 132 AXC 1050 (XC) 9.4.2.3 "Diagnostic Archive" page All diagnostic messages and operating states of the controller are displayed on the "Diag- nostic Archive" page. Figure 9-8 "Diagnostic Archive" page • Click the "Refresh Diagnostic Archive" button to refresh the display.

  • Page 133: Administration" Area

    On the "Password" page, you can assign a password for restoring the factory default set- tings on the controller (refer also toSection 9.4.3.2, “"Factory Defaults" page”). Please note: The password is sent to the network in an unencrypted format. Figure 9-9 "Password" page 8482_en_03 PHOENIX CONTACT...
  • Page 134 AXC 1050 (XC) • Enter the desired new password in the "Enter New Password" input field. Permissible characters: – a ... z – A ... Z – 0 ... 9 – Special characters – Umlauts The password must be between four and twelve characters long.
  • Page 135 Please note: When restoring the factory default settings, all application-specific data (PC Worx (Express) project, IP settings, password, etc.) for the controller is deleted. After restoring the settings, you must reconfigure the controller and assign a new password. 8482_en_03 PHOENIX CONTACT...
  • Page 136 AXC 1050 (XC) Restarting the controller • Deactivate the check box "Reset to factory default settings". • Enter the password in the "Enter password" input field. If you have not changed the password, you have to enter the default password. The de- fault password is private.
  • Page 137 Web-based management (WBM) 9.4.3.3 "Updates via SD card" page On the "Updates via SD card", you will find information on running controller updates. Figure 9-11 "Updates via SD card" page 8482_en_03 PHOENIX CONTACT...

  • Page 138: Webvisu" Area

    AXC 1050 (XC) 9.4.4 "WebVisu" area This area contains a link that you can use to open the WebVisit project of the controller. • Click the "WebVisu" link. Figure 9-12 "WebVisu" link If there is a WebVisit project on the controller, the visualization project is opened in the browser.

  • Page 139: 10 Removing Hardware

    During all work on the Axioline F station, the controller or a module, switch off the power supply to the Axioline F station and make sure the supply voltage is protected against unauthorized re-activation. Figure 10-1 Removing the module so that it is perpendicular to the DIN rail 8482_en_03 PHOENIX CONTACT...

  • Page 140: Removing Cables

    AXC 1050 (XC) 10.2 Removing cables • Disconnect the power to the station. The cables should only ever be removed from the supply plug if you wish to change the ter- minal point assignment or no longer wish to use the supply plug.

  • Page 141: Removing The Sd Card

    (base latches) of the controller one after the other and release it (A in Figure 10-5). The base latches are locked in place in the open position. • Remove the controller perpendicular to the DIN rail (B in Figure 10-5). 8482A017 Figure 10-5 Removing the controller 8482_en_03 PHOENIX CONTACT...

  • Page 142: 11 After Usage

    AXC 1050 (XC) 11 After usage 11.1 Maintenance and servicing The controller is maintenance-free. 11.2 Device replacement The controller can be replaced as required. • Replace the controller in your application with an identical controller (same order num- ber). If you want to replace a controller, follow the steps described in Section 4, “Mounting hard- ware”...

  • Page 143: Device Defect And Repair

    Device defect and repair Repairs may only be carried out by Phoenix Contact. • Send defective devices back to Phoenix Contact for repairs or to receive a replacement device. • We strongly recommend using the original packaging to return equipment.

  • Page 144: 12 Technical Data And Ordering Data

    Depth 74 mm Note on dimensions The specified depth applies when using a TH 35-7.5 DIN rail (according to EN 60715), e.g., NS 35/7.5, etc., from Phoenix Contact, see "Ordering data" on page 148. General data Color Traffic gray A...
  • Page 145 Designation Axioline F plug Connection method Push-in connection Conductor cross section solid 0.2 mm ... 1.5 mm Conductor cross section flexible 0.2 mm ... 1.5 mm Conductor cross section [AWG] 24 ... 16 Stripping length 8 mm 8482_en_03 PHOENIX CONTACT...

  • Page 146: Usb Interface

    AXC 1050 (XC) PROFINET Type PROFINET controller/device Number of supported devices Max. 16 (on the PROFINET controller) Specification Conformance class Performance class Update rate 16 devices 32 ms 8 devices 32 ms 4 devices 16 ms 2 devices 8 ms...

  • Page 147: Extreme Ambient Conditions

    -40°C ... +65°C (up to 3000 m above mean sea level) sea level) For derating information, see Section "Der- ating for the controller AXC 1050 XC" on page 152. For additional information on use of the con- troller in extreme ambient conditions, refer to Section "Tested successfully: Use under...

  • Page 148: Ordering Data

    AXC 1050 (XC) Conformity with EMC Directive 2014/30/EU Immunity test according to EN 61000-6-2 Electrostatic discharge (ESD) EN 61000-4-2/ Criterion B IEC 61000-4-2 6 kV contact discharge 8 kV air discharge Electromagnetic fields EN 61000-4-3 Criterion A IEC 61000-4-3 Field strength: 10 V/m...

  • Page 149: Software

    "Applicative system redundancy" application note AH EN APPLICATIVE SYSTEM RE- – DUNDANCY "Using the atvise® builder software with modular small-scale controllers of AH EN ILC 1X1, AXC 1050(/XC) – – type ILC 1x1 and AXC 1050 (XC)" application note ATVISE 8482_en_03 PHOENIX CONTACT...

  • Page 150: A Appendix

    Remove the SD card. Performing the update • Insert an SD card recommended by Phoenix Contact into an SD card reader and con- nect the card reader to your PC. • In the root directory of the SD card, create the "systemupdate" directory.
  • Page 151 Insert the SD card that had previously been used as main or additional memory back into the controller. • Switch on the supply voltage. Operation without an SD If you had been using the controller without an SD card before updating: card • Switch on the supply voltage. 8482_en_03 PHOENIX CONTACT...

  • Page 152: A 2 Derating For The Controller Axc 1050 Xc

    AXC 1050 (XC) Derating for the controller AXC 1050 XC P [%] T [°C] 8482A019 Figure A-1 Derating for the AXC 1050 XC Key: P [%] Power dissipation as a percentage [°C] Ambient temperature (operation) in °C The specifications refer to a supply voltage of 24 V.

  • Page 153: A 3 Tested Successfully: Use Under Extreme Ambient Conditions

    Tested successfully: Use under extreme ambient conditions Tested successfully: Use under extreme ambient conditions The AXC 1050 XC controller has been tested successfully over 250 temperature change cycles according to IEC 61131-2 in the range from -40°C to +70°C. The following conditions were observed: –...

  • Page 154: B Appendix For Document Lists

    Placing the module vertically .............37 Figure 4-2: Horizontal (A) and vertical (B) mounting position ........39 Figure 4-3: Structure of an Axioline F station with AXC 1050 controller ....40 Figure 4-4: Mounting the bus base modules ............41 Figure 4-5: Snapping on the controller ..............41 Figure 4-6: Inserting the SD card ................42...
  • Page 155 Selecting the USB driver ..............47 Figure 6-2: Project information after creating a new project ........48 Figure 6-3: IP address settings of the controller (AXC 1050) .........50 Figure 6-4: "IP Assignment" dialog: DCP devices are accessible in the network ..51 Figure 6-5: "IP Assignment"...
  • Page 156 Section 7 Figure 7-1: Communication path in Diag+ 2: Start Scan ........79 Figure 7-2: Communication path in Diag+ 2: AXC 1050 (XC) controller found ..80 Figure 7-3: Connection established successfully: selecting the diagnostic view ...80 Figure 7-4: Diagnostic view: selecting "Axioline Diagnostic" .........81 Figure 7-5: Diag+ 2: "Axioline Diagnostic"...
  • Page 157 Figure 10-3: Removing the supply plug ..............140 Figure 10-4: Removing the SD card ..............141 Figure 10-5: Removing the controller ..............141 Appendix A Figure A-1: Derating for the AXC 1050 XC ............152 Figure A-2: Temperature change cycle ...............153 8482_en_03 PHOENIX CONTACT...

  • Page 158: B 2 List Of Tables

    PROFINET system variables (PROFINET device function) ....118 Table 8-5: System variables of the IEC-61131 runtime system......120 Table 8-6: System variables of the control processor .........121 Table 8-7: System variable of the control processor for displaying state information ................121 8482_en_03 PHOENIX CONTACT...
  • Page 159 System variables of the energy storage and real-time clock ....122 Table 8-11: System variables of the power supplies ..........122 Table 8-12: System variables of the mode selector switch ........123 Table 8-13: Project-related system variables............123 Table 8-14: System variables of the system time..........123 8482_en_03 PHOENIX CONTACT...

  • Page 160: B 3 Index

    Delivery state .............. 30 HTTPS ................ 95 Derating ..............152 Hypertext Transfer Protocol Secure (HTTPS) ..... 95 Device defect ............143 Device replacement ..........142 Diag+ Controller context menu ........85 Intended use ..............9 Diagnostic parameter register ........116 8482_en_03 PHOENIX CONTACT...
  • Page 161 Power supply without fall-back characteristic curve ... 43, Removing ............141 Sending a project ............78 Sending e-mails ............96 Service interface ............35 Sizing the power supply ..........43 Software Installing ..............47 Requirements ............15 Startup ................ 47 8482_en_03 PHOENIX CONTACT...
  • Page 162 AXC 1050 (XC) Status indicators ............25 Status information ............. 115 Storage ............... 13 Supply plug ............24, 36 System variables............115 Technical data............144 Transport..............13 Transport damage............13 Unauthorized network access ........10 Unpacking..............14 USB cable Connection ............46 USB driver..............

This manual is also suitable for:

Axc 1050 xc27009882701295

Table of Contents
