Diagnostic And Status Indicators - Phoenix Contact AXC F 1152 Installing, Starting Up, And Operating

AXC F X152
PN/AXC/
PLC
PWR
AXC F 1152 and AXC F 2152
Table 3-1 Controller diagnostic and status indicators
Desig- Color
nation
PN: PROFINET controller/device function
Red/yel-
BF-C
low
Red/yel-
BF-D
low
SF Red
26 / 112
PHOENIX CONTACT
3.9

Diagnostic and status indicators

The diagnostic and status indicators are used for quick local error diagnostics.
BF-C RUN
BF-D FAIL
SF
DBG
BOOT D
EXT E
ETH
UL
X2
X1
Figure 3-10 Diagnostic and status indicators
Meaning State
Status of
PROFINET com- Red on
munication/
Flashing
communication
red (1 Hz)
error
Flashing
yellow
(0.5 Hz)
Status of
PROFINET com-
munication/
Flashing
communication
(1 Hz)
error
Flashing
yellow
(0.5 Hz)
Group error
(PROFINET)
PN/AXC/
PLC
Description
Controller as PROFINET controller
The controller has established an active communication con-
Off
nection to each configured PROFINET device.
No link status on the Ethernet interfaces and/or no 100 Mbit
transmission and/or no full duplex mode.
Link status present, at least one configured PROFINET device
does not have a communication connection.
Flashing for device identification
Controller as PROFINET device
A PROFINET controller has established an active communica-
Off
tion connection to the controller (PROFINET device).
No PROFINET communication (no link status at the Ethernet in-
On
terfaces)
Link status present, no communication connection to the
PROFINET controller
Flashing for device identification
Off PROFINET diagnostics not present
On PROFINET diagnostics present
BF-C RUN
BF-D FAIL
SF DBG
BOOT D
EXT E
UL
X3
a1 b1 X2
X1
b1 b2
ETH
PWR
AXC F 3152
