9.2 Register assignment
The following table shows how the device registers are assigned to addresses that can be
accessed via Modbus/RTU.
Unless otherwise specified, the numerical values are decimal values.
Access Memory
Read Retentive
Read Retentive
Read Retentive
Retentive
Read Retentive
Read Retentive
Read Retentive
Read Retentive
Read Retentive
Read Retentive
Read Retentive
Function
Order designation
Order number
Serial number
Year of manufacture
Manufacturing date
Hardware identification
Hardware version
Firmware: identification letter
and major version number
Firmware: version number
Firmware: minor version num-
ber
Coding
ASCII (32 characters)
ASCII (10 characters)
ASCII (12 characters)
YYYY (4 x 4 bits BCD)
MM.DD (4 x 4 bits BCD)
ASCII (MSB) + integer (LSB)
Integer
ASCII (MSB) + integer (LSB)
Integer
Integer
