Phoenix Contact EV Charge Control Basic User Manual page 57

Table 9-2 Register assignment
Type Address Value
Hold- 4009 16 bits
ing
4010 16 bits
4011 16 bits
4012 16 bits
4013 16 bits
106377_en_04
Access Memory
Read –
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read/write Retentive
Function
Configuring connection of
case B or C
Relevant for EV-CC-AC1-M3-
CBC-... only
Permitting vehicles with
charging status D (ventilation
required)
Function activation for con-
necting the EV-RCM residual
current monitoring device at
input XR
S1/DIP 2 must be set to
"OFF".
EV-RCM =
– EV-RCM-C1-AC30-DC6,
1622450
– EV-RCM-C2-AC30-DC6,
1622451
Optional reset in the event of
an error. A function test (de-
vice test) is performed upon
device start and following
every charging process.
Function activation for
charging current adaptation
via input CCR. Charging con-
tactor monitoring must be de-
activated (register 4006 = 0)
Threshold value for switching
off (0 A) or switching on (6 A)
the charging process, with an-
alog evaluation of input CCR
Modbus description
Coding
Integer
If S1/DIP 5 = OFF:
0: Connection of case B, Infra-
structure Socket Outlet
If S1/DIP 5 = ON:
1: Connection of case C, Vehicle
Connector
Integer
0: Do not permit charging in sta-
tus D (default)
1: Permit charging in status D
Integer
0: Deactivated
1: EV-RCM connection acti-
vated; automatic reset active; au-
tomatic device test active
2: EV-RCM connection acti-
vated; automatic reset inactive;
automatic device test active
3: EV-RCM connection acti-
vated; automatic reset active; au-
tomatic device test inactive
4: EV-RCM connection acti-
vated; automatic reset inactive;
automatic device test inactive
Integer
0: Deactivated
1: Digital evaluation (see
Table 2-3) (default)
2: Evaluation as analog signal (to
use a charging current controller)
Integer in mV
Default = 0 mV
