Phoenix Contact EV Charge Control Basic User Manual page 59

Table 9-2 Register assignment
Type Address Value
Hold- 7001 16 bits
ing
7002 16 bits
7003 16 bits
7004 16 bits
7010 16 bits
7011 16 bits
7500 16 bits
7501 16 bits
7502 16 bits
7503 16 bits
106377_en_04
Access Memory
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read/write Retentive
Read/write Retentive
Function
Configuring the operating time
of the charging connector
locking during opening and
closing
Relevant for EV-CC-AC1-M3-
CBC-... only
Maximum number of locking
cycles without cooling phase
Repetitions in the event of un-
successful locking attempts
Break between two locking
sequences
Maximum permissible operat-
ing time of the locking actuator
in continuous mode
Evaluating the locking feed-
back
Setpoint resistance between
LD1 and LD2 in the "charging
connector not locked" status
Evaluating the locking feed-
back
Setpoint resistance between
LD1 and LD2 in the "charging
connector locked" status
Dimming the on-board LED
PWR
Dimming the on-board LED
CON
Dimming the on-board LED
ERR
Dimming the on-board LED
CHR
Modbus description
Coding
Integer, in ms
Default = 600 ms
Integer
Default = 5
Integer, in ms
Default = 1000 ms
Integer, in ‰
Default = 50‰
Integer, in ohms
Default = 65535 (floating switch
as confirmation contact open)
Integer, in ohms
Default = 0 (floating switch as
confirmation contact closed)
Integer, 1 x 16 bits
Percentage, pulse duty factor
0% ... 100%
Integer, 1 x 16 bits
Percentage, pulse duty factor
0% ... 100%
Integer, 1 x 16 bits
Percentage, pulse duty factor
0% ... 100%
Integer, 1 x 16 bits
Percentage, pulse duty factor
0% ... 100%
PHOENIX CONTACT
59 / 68
