Charging Sequence 6 - Phoenix Contact EV Charge Control Basic User Manual

EV Charge Control Basic
S1/DIP 1 = OFF
S1/DIP 5 = ON
(32 A)
S1/DIP 6 = OFF
52 / 68
PHOENIX CONTACT
8.6

Charging sequence 6

Charging sequence according to connection example 7.6,
via analog CCR signal".
Figure 8-6 Charging sequence 6
EV Charge Control Basic
EV Charge Control basic
IEC 61 85 1-1
Mode 3
CP
12V
9V
6V
3V
0V
-12V
PP[ Ω ]
∞
1500
680
220
100
0
EN
1
0
XR
1
0
ML
1
0
CCR
10 V
3 V
C1/
closed
open
C2
+12V
LO+/
0
LO-
- 12 V
LD
1
0
ERR
1
0
CHG
1
0
CON
1
0
S S S
1 2 3
S1
S S S
4 5 6
"Charging current control
32 A
1
0
1 2 3 4 5 6 7 8
S S S S
7 8 9 10
106377_en_04
