S1/DIP 1 = OFF
S1/DIP 5 = ON
EV-CC-AC1-M3-CBC-...,
connection of case B
230 V
L, L1-L3
106377_en_04
7.3 Charging enabled with local release and charging
current reduction
Charging station with Infrastructure Socket Outlet
Charging current preset to 32 A
Locking is carried out if the vehicle is detected at the charging station.
The charging process starts if locking is detected, switch k1 is closed, and status C is
present.
– If switch k2 is closed, the charging current (PWM signal) is reduced during this time
(see Table 2-3 on page
Figure 7-3 Connection example 3
N
PE
13).
k2
k1
S1 S2
PWR
CON
ERR
CHR
RD
GN
YE
BN
Connection examples
32 A
1
S1
0
M
EV-T2M3SE12-3AC...
PHOENIX CONTACT
37 / 68
