Table 9-2 Register assignment
Type Address Value
Coils 20000 1 bit
20001 1 bit
20002 1 bit
20003 1 bit
21000 1 bit
Hold- 21100 16 bits
ing
22000 16 bits
23000 16 bits
60 / 68
PHOENIX CONTACT
Access Memory
Read/write Volatile
Read/write Volatile
Read/write Volatile
Read/write Volatile
Read/write Volatile
Read/write Volatile
Read/write Volatile
Read/write Volatile
Function
Enabling the charging process
Switching on the PWM signal
if all other conditions required
are met.
Only takes effect if register
4000 is configured for this
function.
Setting the system state F (ac-
cording to IEC 61851-1) if the
charging station is not avail-
able.
Only takes effect if register
4001 is configured via
Modbus/RTU.
Controlling the locking actua-
tor
Only takes effect if register
4002 is configured for this
function.
EV-RCM function test
Restarting the charging con-
troller
Resetting to default settings
Setting the maximum permis-
sible charging current
Setting the digital output regis-
ter for output OUT
Only takes effect if the digital
output OUT is configured with
value 0 via register 5500 (see
Table 9-3).
Coding
1 bit
0 = charging process not enabled
1 = charging process enabled
1 bit
0 = charging station not available,
status F
1 = charging station available
1 bit
0 = charging connector is un-
locked
1 = charging connector is locked
1 = EV-RCM function test follow-
ing the next charging process
(status A1 or B1). After the func-
tion test, the register is set to 0.
1 bit
Restart if value 1 is written.
Integer
Reset if value 17281 is written.
Integer
Maximum permissible charging
current
6 A ... 63 A
Integer
0: Output = OFF
1: Output = ON
2: Output = flashing (1 Hz)
