EV Charge Control Basic
Table 2-1 Connections [...]
No. Name Meaning
3 LO- Locking
LO+
LD2 Lock Detection
LD1
PP Proximity Plug
CP Control Pilot
4 SG Signal Ground
B RS-485
A
5 C2 Contactor
C1
*
Not protected against overload
†
Not for EV-CC-AC1-M3-CC-...
10 / 68
PHOENIX CONTACT
Description
Control of the locking actuator
Digital input, for connecting the locking confirmation, can be configured
Test signal
Pilot wire signal
Ground signal for the RS-485 communication interface
Communication interface
Relay output, charging contactor
For further information on the configuration options for the digital inputs and outputs,
please refer to the "Modbus description" on page
Current carrying capacity of the connected
charging connector and charging cable ac-
cording to
IEC 61851-1
Communication between charging station and
vehicle according to IEC 61851-1, SAE J1772
and GB/T 18487.1
Switches the mains voltage to the vehicle via an
external
charging contactor when status C or D is reached
and
the enabled inputs and registers are active.
53.
†
†
†
