Connection examples
S1/DIP 1 = OFF
S1/DIP 6 = ON
S1/DIP 5 = ON
EV-CC-AC1-M3-CBC-...,
connection of case B
230 V
L, L1-L3
106377_en_04
This section shows some connection examples how the charging controller can be used.
Other options result from the configuration via configuration switches S1 and S2 and the
configuration of the digital inputs and outputs via Modbus/RTU. For the configuration op-
tions, please refer to Table
scription" on page
7.1
Charging enabled with local release
Charging station with Infrastructure Socket Outlet
Charging current preset to 20 A or
Charging current preset to 32 A
Locking is carried out if a vehicle is detected.
The charging process starts if the locking feedback is available, switch k1 is closed, and
status C is present.
Figure 7-1
Connection example 1
N
PE
"Configuration switches S1 + S2" on page 13
53.
k1
S1
S2
PWR
CON
ERR
CHR
Connection examples
20 A
1
S1
0
32 A
1
S1
0
RD
GN
YE
M
BN
EV-T2M3SE12-3AC...
PHOENIX CONTACT
and
"Modbus de-
35 / 68
