Phoenix Contact EV Charge Control Basic User Manual page 62

EV Charge Control Basic
Table 9-2 Register assignment
Type Address Value
Hold- 24017 16 bits
ing
24018 16 bits
24019 16 bits
24020 16 bits
24025 16 bits
24027 16 bits
26000 16 bits
26001 16 bits
62 / 68
PHOENIX CONTACT
Access Memory
Read Volatile
Read Volatile
Read Volatile
Read Volatile
Read Volatile
Read –
Read Volatile
Read Volatile
Function
Minutes counter and seconds
counter in status C and D,
reset condition via status A
Hours counter in status C and
D, reset condition via status A
Minutes counter and seconds
counter in status B, C and D,
reset condition via status A
Hours counter in status B, C
and D, reset condition via sta-
tus A
Error status
Presetting the maximum cur-
rent setting via S1/DIP 5 + 6
Evaluating input EN as analog
input
Evaluating input XR as analog
input
Coding
Integer, 2 x 8 bits
mm:ss
Integer, 1 x 16 bits
hhhh
Integer, 2 x 8 bits
mm:ss
Integer, 1 x 16 bits
hhhh
Bit = error assignment
Bit 2 = rejection of 13 A cable
Bit 3 = invalid PP value
Bit 4 = invalid CP value
Bit 5 = status F due to no
charging station availability
Bit 6 = locking
Bit 7 = unlocking
Bit 8 = LD unavailable during
locking
Bit 11 = status D, vehicle re-
jected
Bit 12 = charging contactor error
Bit 13 = no diode in the Control
Pilot circuit in the vehicle
Bit 15 = EV-RCM residual current
detection triggered
Bit 16 = EV-RCM selftest error
Integer, 1 x 16 bits
Integer, 1 x 16 bits
Standardized to mV
Integer, 1 x 16 bits
Standardized to mV
