Charging Sequence 5 - Phoenix Contact EV Charge Control Basic User Manual

S1/DIP 1 = OFF
S1/DIP 2 = ON
106377_en_04
8.5

Charging sequence 5

The charging sequence shows an availability test via the XR input and the charging enabled
status via the EN input.
Figure 8-5 Charging sequence 5
EV Charge Control Basic
EV Charge Control basic
IEC 61 85 1-1
Mode 3
CP
12V
9V
6V
3V
0V
-12V
PP[ Ω ]
∞
1500
680
220
100
0
EN
1
0
XR
1
0
ML
1
0
CCR
1
0
C1/
closed
open
C2
+12V
LO+/
0
LO-
- 12 V
LD
1
0
ERR
1
0
CHG
1
0
CON
1
0
S S
1
S S S
2 3 4 5
Flow charts for the charging process
1
S1
0
1 2 3 4 5 6 7 8
S S S
6 7 8
