DLP-17 Configuring the Total Access 850 for Dual T1 Maps

Introduction
The Total Access 850 with firmware A.04.02 or higher has a
T1 connections for the termination of data and voice applications. The primary network
configured for internal router usage (FT1/24 DS0s maximum) and to any access module installed. The
can be used for FXS/FXO modules in slots 1-6 only. There are several steps that must be
DSX M
AP
followed in order for the Dual T1 Map to be configured successfully. These steps are described in this DLP.
Prerequisite Procedures
This procedure assumes that the user has access to the Total Access 850 system menus.
Refer to DLP-1, Connecting a VT100 Terminal or PC to the CRAFT Port, for details on
making a terminal connection to the Total Access 850.
To prevent electrical shock, do not install equipment in a wet location or during a
lightning storm.
Electronic modules can be damaged by static electrical discharge. Before handling
modules, put on an antistatic discharge wrist strap to prevent damage to electronic
components. Place modules in antistatic packing material when transporting or storing.
When working on modules, always place them on an approved antistatic mat that is
electrically grounded.
64203376L1-1B
D T1 M
UAL
© 2004 ADTRAN, Inc.
feature that allows two network
AP
T1 M
AP
can be
