Auto-Configuration

I M
NTERFACE ANAGEMENT
a summary of the LMA settings (columns 3,4) needed to achieve a
desired interface type and IME type (columns 1,2).
Table 16 Setting Interface Type and IME Type through LMA
To configure and
interface type IME type
to to
E-IISP User Side
E-IISP Network Side
IISP User Side
IISP Network Side
UNI Network Side
Viewing Auto-Discovery Results
You can view:


If auto-discovery is enabled or not.


If auto-discovery or manual discovery was used.


The IME type and the Interface type that are actually running on the
port and also how they were determined.
For examples see "Display Auto-Discovery Results" on page 142 in the
Management Guide.
The adjacent IMEs inform each other of their capabilities and jointly
determine the maximum parameter values they have in common (see
Table 6 for auto-configuration parameter list).


ILMI Version


UNI Signalling Version


NNI Signalling Version


VPI/VCI range


Maximum Number of Active VPI Bits


Maximum Number of Active VCI Bits


Maximum SVPC VPI


Maximum SVCC VPI


Minimum SVCC VCI
set LMA and LMA
port profile port interface
to type to
User E-IISP
Network E-IISP
User IISP
Network IISP
User or Network UNI
