commands. The following table shows the various operational states that
can occur when you disable either auto-discovery or auto-configuration:
Table 7 Auto-Discovery and Auto-Configuration States
Auto-Discovery On
Auto-Discovery Off

Auto-Discovery

The auto-discovery procedure configures the two parameters: ATM
Interface type and IME Type.
ATM Interface type and IME Type are determined automatically by
auto-discovery only when both adjacent IMEs are running ILMI version
4.0. Otherwise, the manual settings are used as shown in the sections
below.
The ATM interface type determines the interface protocol used by the
port and can be one of the following:








PNNI is available in version 4.5 extended only.
The ports are initialized to the UNI interface type at the factory. You do
not need to manually reset the interface type except as indicated in the
following sections.
The IME type determines the role that the port assumes vis-a-vis its peer
and can be one of the following:






UNI—for communicating with an edge device or ATM end-user (user)
E-IISP—for communicating with a 3Com network device (node)
IISP—for communicating with a third party network device (node)
NNI/PNNI—for communicated between network devices (node)
User-Side
Network-Side
Symmetric
Automatic Configuration Procedures
Auto-Configuration On
Auto-discovery and
auto-configuration
operate normally.
Use manual discovery.
Auto-configuration
operates normally.
43
Auto-Configuration Off
Use manual discovery and
user configuration via
LMA.
Use manual discovery and
user configuration via
LMA.
