40 C 2: N
HAPTER ETWORK
I M
NTERFACE ANAGEMENT
International Code Designator is maintained by the British Standards
Institute. The length of this field is two octets.


E.164 ATM format — specifies Integrated Services Digital Network
numbers. A public network addressing standard utilizing up to a
maximum of 15 digits.
Multiple Addresses Registered at Port
Each port can have more than one ATM address registered in its MIB
address table. This occurs when the attached edge device has more than
one ATM-addressable component. For example, edge devices such as
SuperStack II, Switch 2700 and the CoreBuilder 7X00 interface cards can
have multiple ATM-addressable Ethernet bridges. The ATM address of
each bridge is registered by ILMI at the port to which the edge device is
connected.
The number of addresses that can be registered at an ATM port depends
on the type of CoreBuilder 7000 switch and the software version as
shown in Table 5:
Table 5 Maximum Number of Addresses Registered at a Port
Switch Type
CoreBuilder 7000
CoreBuilder 7000HD
Referencing Calls by Destination ATM Address - Member ID
For easy reference, each ATM address registered at a port is assigned a
member ID. The member ID, which is specific to the CoreBuilder 7000
family ATM switch, consists of the port number followed by a two-digit
number of the form 0n where 01 corresponds to the first ATM address
registered, 02 to the second, and so on. For example, the member ID for
the first ATM address registered at port <3.3> is 3301.
The member ID is useful for displaying information about calls that are
associated with the ATM address. For example, if a switched virtual
channel is established through to the LEC whose ATM address is
Memory Size
Software Version (MB)
4.0 Basic 8
4.0 Extended 8
4.0 Basic 16, 32
4.0 Extended 16, 32
Number of
Addresses per
Port
19
12
31
31
