Communication
Methods

Security

M
ANAGEMENT
Viewing the event log
n
Local Management can operate via a terminal, workstation or PC running
a terminal emulation program, and can use the following communication
resources (see Figure 59):
RS-232 serial link.
n
RS-232 serial link + modem (for use with a remote terminal).
n
Telnet over TCP/IP through the Ethernet port.
n
At system setup, you must activate the LMA to configure the
communication modes needed to access the agents through the various
networks. Refer to the Installation and Startup Guide for additional
configuration information.
Local Management security rests on a hierarchy of passwords: Admin,
Write and Read. For additional information on Local Management
security, see the Installation and Startup Guide.
CB7000 Switch Module
[1] SYS: Platform config.
[2] LEM: Lan Emulation
[3] CON: Connections
[4] STS: Statistics
[5] DIA: Testing & Diagnostics
[6] FTR: ATM features
[7] LOG: Logout
[8] VER: Version
[9] FST: Fast Setup
Figure 59 CoreBuilder 7000 Family ATM Switch Administration Console
Telnet
PC
Terminal
Workstation
CoreBuilder 7000
