Flow
Enable ____________________
Pulses ____________________
Pull ____________________
The setting 'Enable' can be programmed as: ON / Add / Substract.
'Add' means Flow 2 will be added to Flow 1
'Substract' means Flow 2 will be subtracted from Flow 1
Flows per sensor are indicated in the main screen. Total flow (e.g. Flow 1 – Flow 2) is
indicated in the 103 Job menu.
If Flow 3 is enabled at 'Add' or 'Substract' it will be added or subtracted from Flow 1 as well.
Flow meter functioning can be checked in menu 211.
Pressure 1
Enable ____________________
Low ____________________
High ____________________
Cal. ____________________
Offset ____________________
Smooth ____________________
Type V/I ____________________
Mostly, a pressure sensor is a voltage sensor (V), not a current sensor (I). Smooth can stay
at 50.00%.
Pump
Pump refers to the small ARB air compressor to supply air to the Ramsey valve.
This menu is only applicable when the system has a PSU with compressor switch.
Enable ____________________
Off in Hold ____________________
Max on ____________________
Delay ____________________
