7.2.5 PWM mode/Nozzle selection menu (104)

This menu is not available while driving the vehicle. This means that you will

have to stop the vehicle before you can select a different nozzle cap or set the

application rate.

Use menu 104 to select the spraying mode and the nozzle type to be used.

WEED-IT can be used in various modes:

Spot spraying

Full coverage

Dual (spot & cover)

By default, PWM (Pulse Width Modulation) is disabled. If PWM is disabled, menu 104 looks

like this:

After changing the PWM mode or the application rate, all sensors must be reconfigured.

Press the OK key to confirm the new settings and update all sensors. This may take a couple

of seconds:

The system automatically restarts.

Spot spraying mode

Press the Mode key to enable Spot spraying mode . The screen changes:

WEED-IT Quadro | User Manual - BT-UMWEEDQ-B | 45 / 82
