4.4 Cleaning nozzles

Flush the nozzles regularly with clean water to avoid clogging.
1. Fill the tank with water.
2. Start the system.
3. Wait until the Main screen opens.
4. Press to flush all nozzles.
Use one of the following methods to clean an individual nozzle more thoroughly:
Service Mode (100):
1. Make sure there are no plants in the detection line.
2. Stop the vehicle.
3. Enter the Service mode.
4. Use the Sensor information menu to switch off the sensors that do not need to
activate nozzles.
Use the nozzle cleaning menu (102):
1. Make sure there are no plants in the detection line (to prevent the corresponding
nozzles from spraying continuously in step 6).
2. Stop the vehicle.
3. Enter the Service mode.
4. Press repeatedly until menu 102 opens.
5. Press to activate Detection. As long as Detection is active, the leaf icon will flash.
6. Activate the nozzle by supplying chlorophyl (green plant material) in the
corresponding sensor channel.
7. Press again to stop.
8. Press to return to the Main screen.

4.5 Reading job productivity

Several options are available to check job productivity apart from the information given in
the Main screen.
1. Enter the Service mode.
2. Press repeatedly until menu 103 opens.
Refer to "Job menu (103)" on page 44 for more information.
28 / 82 | WEED-IT Quadro | User Manual - BT-UMWEEDQ-B
