1. About this manual

This manual is intended for users of the WEED-IT system. It describes how to use the WEED-
IT system and how to perform basic maintenance.
Please read this User Manual and the safety instructions carefully before you start to use the
WEED-IT system.
This manual contains:
Section 1: General information about this manual.
Section 2: General information about the WEED-IT system and important safety
information.
Section 3: Identification of parts in the system. Extensive information about the
various parts and controls of the WEED-IT system.
Section 4: General instructions for use of the WEED-IT system.
Section 5: General maintenance instructions.
Section 6: Instructions for cleaning, storage and transport.
Section 7: Control unit reference section, with a description of available menus.
Section 8: Troubleshooting information.
Section 9: Specifications.
Section 10: Menu options overview.
Section 11: Calibration settings form.
An index has been added to make finding the required information easier.

1.1 Conventions

bold type
monospace type

1.2 Icons

The following icons are used in this manual to point out or to clarify information related to
safety and safe use of the WEED-IT:
This sign draws attention to a WARNING or a CAUTION.
WARNING: Personal injury may occur if you do not follow instructions.
CAUTION: Damage to equipment may occur if you do not follow instructions.
used for emphasis
for display texts
