Measurement toggle: Use this key to toggle between various types of
measurement displays in the top right corner of the display:
Note that in the Main screen, the bottom line changes every three seconds.
Press briefly to move to the next menu.
7.1.2 Preset menu options
Use the Preset menu to change the spraying margin and sensitivity of the WEED-IT.
Histogram: see description Main menu.
Margin: WEED-IT uses a certain margin when spraying a target. This
margin varies from 200 ~ 300 mm and specifies the distance before and
after the weed to be sprayed.
One of four predefined margins can be selected while driving the vehicle.
The number of the selected margin is displayed to the left of the icon.
The margin-setting is often used to compensate for the spray
displacement caused by heavy winds, or uneven terrain / strong
variation in terrain. By default, the margin presets are defined as
follows:
1.200 mm
2.230 mm
3.270 mm
4.300 mm
Hold: see description Main menu
