Two extra parameters are now available for selection:
the nozzle type
the application rate
To change settings:
1. Stop the vehicle.
2. Use the Left/Right navigation keys to change the application rate. This amount of
herbicide mix is only applied to the weeds that are detected by the system. The
herbicide is applied at the same application rate for any speed up to the optimum
speed and also while turning.
3. Use the Up navigation key to change the nozzle type. The first parameter is
highlighted:
4. To correctly calculate how much spraying liquid is applied, WEED-IT needs to know
which nozzle type is used. When mounting a different type of nozzle, use menu 104 to
select the appropriate type before proceeding. This nozzle is used for all PWM modes.
Use the Left/Right navigation keys to select the appropriate nozzle type.
5. Press OK to confirm. All sensors are reconfigured and the system restarts.
Only use the nozzle types that you can select in the software.
The nozzle type is usually engraved in the top surface of the nozzle.
Full coverage mode
Full coverage mode will spray liquid continuously, like in a regular spraying application. The
sprayed amount is independent of the driving speed, turning and detection.
Press the Mode key to enter Full coverage mode.
Set the Cover parameter to adjust the amount of liquid used (application rate).
