Make sure that every person who has access to the Control unit is familiar
with all safety information provided in "Important safety information" on
page 8.
On/Off
Display
See "Display" on the next
page
Function keys
See "Function keys" on
page 22
Navigation keys
See "Navigation keys" on
page 23
Menu key

3.2.1 On/Off switch

The On/Off switch is located at the top left of the Control unit.
Press for 1 second to switch on the WEED-IT system
Press briefly to switch off the WEED-IT system.
Press the On/Off switch to turn the WEED-IT on or off.
At start-up, the display shows the Start-up screen. The display
shows the system status and other relevant information such
as warnings, errors, driving speed, pressure and several menu
items.
The function of these five keys depends on the menu level. Each
key corresponds with a function displayed in the screen.
Use the navigation keys to select a value or to move through
the items in the menu.
Use the Menu key to change the menu level, the menu within a
level, or to access a different user mode.
WEED-IT Quadro | User Manual -BT-UMWEEDQ-B 19 / 82
