Sensor model and firmware version.
Type
Serial number of the sensor.
Serial
Temperature Temperature inside the sensor.
Humidity inside the sensor. If the value is too high, a message opens in
Humidity
the screen. Have the sensor replaced by your supplier.
Current status of the sensor (e.g. Running, Error, Off, ....).
Status
Status of the individual nozzles. Nozzle failures are indicated with a cross
Nozzle
(see nozzle number 3):
Function keys in the Sensor Information menu have the following meaning:
Press this key to leave the Service mode and to return to the Main
screen.
Press this key to turn the selected sensor on or off.
Press this key to go to the Previous sensor.
Press this key to go to the Next sensor.
7.2.2 Warnings menu (101)
In the Main screen, warnings are displayed directly below the speed bar. If there are no
warnings or messages to display, a clock is shown. Only one message at a time can be shown
here:
Because the screen is rather small, messages/warnings will be very short. If more than one
message is pending, or if multiple errors occur at the same time, each message is shown for a
few seconds.
42 / 82 | WEED-IT Quadro | User Manual - BT-UMWEEDQ-B
