Make sure that sensor windows are clean. The cleaner the sensor windows,
the more accurate the detection.
The system can operate at a maximum speed of 25 km/h (15.5 mph). To be
able to drive the system at that speed:
the distance between the detection line and the nozzles must be at least
600 mm (24 inch)
the pressure must be 3.0 bar (43.5 psi)(but at least 2.5 bar/36.3 psi)
nozzle height must be less than 600 mm (24 inch)
margin must be between 200 & 300mm
Battery voltage must be between 11.7 and 18 V for proper operation.
Whenever the battery voltage drops below 11.7 Volt, a warning will be
issued; the system switches off when the voltage drops below approx.
11.5 V.
The alternator must have a charging capacity of at least 100 Amp. For
systems with more than 30 sensors, we recommend at least 150 Amp.
For 36-meter systems, we recommend to have a 200 A alternator.
Flush the valves (nozzles) regularly with clean water to avoid clogging.
Sensitivity of the sensors may have to be adjusted, depending on
circumstances. Refer to "Changing sensitivity" on page 31 for more
information.
We recommend to use at least a 100 mesh pressure filter in your
sprayer to prevent solenoid valve clogging or damage due to particles.

4.1 Main menu and Service mode

Two User levels are available:
Main menu: This is the default mode. With the main screen open, briefly press
to navigate through available menus. If no key is pressed for 3 seconds, the system
takes you back to the Main screen. Refer to "Main menu options" on page 37 for
more information on available options.
Service mode: Use this mode to check and/or change system settings. Press and hold
for 1 second to enter the Service mode. Refer to "Service mode" on page 40 for
more information on available options.

4.2 Pressure check

Before each use, check system pressure by briefly flushing the WEED-IT system:
Note this is also a good practice to clear excess dust build-up especially after transporting some distance.
