At System start-up:
1. You will hear a short beep. The Start-up screen opens.
It shows:
Control unit serial number
Firmware version number (the software inside the WEED-IT)
Firmware release date
Current date and time
3. The system does a self-test and the Control unit communicates with the Power
converter (to which all components are connected).
4. Once the self-test is completed, the Main screen opens.

3.2.2 Display

When you switch on the WEED-IT system, the Start-up screen opens. Immediately after that,
the Main screen opens:
The screen above shows a system that has 20 sensors (10 on either side, identified as
A through J).
The top of the screen shows a number of important values (subject to system
settings).
Refer to "Main menu options" on page 37 for information on specific main menu options.
Please note that Main screen content depends on the number of installed
options, current settings and on the number of connected sensors.
