4. Use the Up/Down navigation keys to select the nozzle parameter, if necessary.
5. Use the Left/Right navigation keys to select the appropriate nozzle type.
6. Press OK to confirm. All sensors are reconfigured and the system restarts.
Only use the nozzle types that you can select in the software.
The nozzle type is usually engraved in the top surface of the nozzle.
For more information, see "PWM mode/Nozzle selection menu (104)" on page 45.

4.8 Changing application rate

Follow the steps below if you want to change the application rate:
1. Stop the vehicle.
2. Enter the Service mode.
3. Press briefly a number of times, until menu 104 opens:
4. Use the Up/Down navigation keys to select the Spot and/or Cover parameter if
necessary; use the Left/Right navigation keys to change the application rate.
The spot parameter determines the amount of herbicide mix that is applied to
the weeds that are detected by the system. The herbicide is applied at the
selected application rate for any speed up to 25 km/h and also while turning.
The cover parameter determines the amount of herbicide mix that is applied to
the entire field (full coverage mode) or the rest of the field (dual function
mode).
