4.6 Changing the PWM mode

WEED-IT can be used in various modes:
Spot spraying, see "Spot spraying mode" on page 45
Full coverage, see "Full coverage mode" on page 46
Dual function (spot & coverage), see "Dual function" on page 48
To change the spraying mode:
1. Stop the vehicle.
2. Enter the Service mode. The global information screen opens:
3. Press briefly a number of times, until menu 104 opens:
4. Press the Mode function key to select the PWM mode you wish to use.
5. Adjust the available parameters to match your nozzle type and preferred spray rates.
6. Press OK to confirm. All sensors are reconfigured and the system restarts.

4.7 Setting the nozzle type

Follow the steps below if you have replaced nozzles on the WEED-IT by a new type:
1. Stop the vehicle.
2. Enter the Service mode.
3. Press briefly a number of times, until menu 104 opens:
WEED-IT Quadro | User Manual - BT-UMWEEDQ-B | 29 / 82
