7.2.4 Job menu (103)
Use the Current job menu to view the recorded data of the current job.
Liquid can be determined if at least one flow meter has been installed that registers the
liquid flow to the nozzles. To determine the amount of herbicide, the Dose variable must be
correctly set (e.g. 10 % means 10 liters of herbicide per 100 liters of liquid).
WEED-IT remembers usage parameters of the 7 previous jobs (or 7 previous days, depending
on settings).
When you enter menu 103, the screen shows the current job totals (or the current day
totals), indicated as page 8/8:
Time Duration of the current job
Active Current job covered distanced
Area Current job covered area
Dose % of the herbicide used in the mixture. Use the Left/Right navigation
keys to adapt the value. Press
Liquid Total volume of liquid sprayed for the current job
Usage Total volume of liquid used per Ha (Liquid divided by Area) for the current
job
Use this key to return to the Main menu
Use this key to start a new job. Please note that a maximum of 8 jobs can
bed saved. If you start a new job, the data for the first job is deleted.
By default, the details in menu 103 are stored per job. If you save data
per job, you can monitor multiple jobs on a single day. However, your
Supplier/Dealer can change this to storing data per day.
Use this key to confirm a setting
The first screen shows the current job . However, you can also view totals
of the previous 7 jobs on which the WEED-IT was used. Press
scroll through the screens. The top of each screen shows the date on
which the data was recorded.
When viewing the current job, the screen is not refreshed to make sure
that you can read the values. Press
44 / 82 | WEED-IT Quadro | User Manual - BT-UMWEEDQ-B
to confirm.
at any time to refresh the screen.
and to
