Croplands WEED-IT Quadro User Manual page 43

Figure 7-3 Warnings Global screen - no warnings or error messages
Warnings are shown in a list. If the list is too long to fit the screen, use the
access the rest of the list.
All warnings and error messages are stored when the WEED-IT is switched off. To clear
the list of warnings, press the
Errors or warnings that are persistent will re-appear.
7.2.3 Nozzle cleaning menu (102)
The Nozzle cleaning menu is only available when the vehicle is not moving.
Use the Nozzle cleaning menu to:
flush nozzles
test detection
test solenoid valves
check nozzles
Press the Exit key to leave the Service mode. The main screen opens.
Press the Chase key to activate nozzles one by one with a short burst.
Press the Detection key test nozzles. Holding a leaf under a sensor
should activate the corresponding nozzle.
Press the Sequencing key to activate nozzles one by one with a long
burst.
Press the Melody key to activate nozzle cleaning at a variety of
frequencies, simulating PWM control.
key.
WEED-IT Quadro | User Manual - BT-UMWEEDQ-B | 43 / 82
and keys to
