Machine On Hold - Croplands WEED-IT Quadro User Manual

1. From the Main screen, press
2. Use to select the desired preset. This function allows the WEED-IT to be used under
different / reflective or changing conditions such as wet surfaces after rain, freshly
harvested crops, in bright sunlight, at night or with very small plants. Each preset has
a number; the number is displayed on the sensitivity key and in the top right of the
screen. A low number means a high sensitivity and a high number means a low
sensitivity:
Figure 4-1 Preset number 2 selected
You may have to experiment to find the appropriate setting. Check the display to
verify sensor response. A series of vertical bars under the sensor icons indicates the
activity of each sensor.
Refer to "Preset menu options " on page 39 for more information on presets.

4.11 Machine on hold

Use the Hold function to temporarily stop spraying, for example when turning on headlands:
In the main screen, press the
Press once more to resume spraying.
If you have installed an external hold switch you can use this switch as well as the function
key.
32 / 82 | WEED-IT Quadro | User Manual - BT-UMWEEDQ-B
once to enter the Preset menu.
function key.
