Table 3-8: Control Wiring Instructions — NEMA Type 1/12 Open Drives
Mounting Drive
1. Mount Drive
(See Table below for dimensions.)
VSD Series Open Drive Dimensions
Frame Voltage hp (VT)
Size
FR4 230V 3/4 – 3
480V 1 – 5
FR5 230V 5 – 7-1/2
480V 7-1/2 – 15
FR6 230V 10 – 15
480V 20 – 30
575V 2 – 25
FR7 230V 20 – 30
480V 40 – 60
575V 30 – 40
FR8 480V 75 – 125
575V 50 – 75
FR9 480V 150 – 200
575V 100 – 150
FR10 480V 250 – 350
575V 200 – 300
Power Wiring
Do not discard the plastic bag containing the wiring plate.
2. Remove the bottom cover by rotating the cover toward
you on the base hinges, then lifting the cover away from
the base.
Power Wiring
3. Locate the plastic bag shipped with the drive containing
the wiring plate, and remove the wiring plate.
LIT-1201828
NEMA Type 1/12 Open Drives (1 – 250 HP)
Approximate Dimensions in Inches (mm)
H1 H2 H3
12.9 12.3 11.5
(327) (313) (292)
16.5 16.0 15.4
(419) (406) (391)
22.0 21.3 20.4
(558) (541) (519)
24.8 24.2 23.3
(630) (614) (591)
29.7 28.8 28.4
(755) (732) (721)
45.3 44.1 —
(1150) (1120)
44 33.5 —
(1120) (850)
Notice
For more information visit: www.johnsoncontrols.com
D1
H1
H2
H3

Figure 3-2:

D1 D2 D3 W1
7.5 2.5 5.0 5.0
(190) (64) (126) (128)
8.4 2.7 5.8 5.7
(214) (68) (148) (144)
9.3 2.7 6.7 7.7
(237) (68) (171) (195)
10.1 2.7 7.5 9.3
(257) (68) (189) (237)
11.3 1.3 11.0 11.2
(288) (34) (279) (285)
14.3 5.4 8.8 18.9
(362) (137) (224) (480)
23.6 NA NA 23.6
(600) (600)
VSD Series Drives User Manual
W1
R2
W2
R1
D2
D3
R2
Knockouts
W2 R1 dia. R2 dia.
3.9 .5 .3
(100) (13) (7)
3.9 .5 .3
(100) (13) (7)
5.8 .7 .4
(148) (18) (9)
7.5 .7 .4
(190) (18) (9)
10.0 .7 .4
(255) (18) (9)
15.7 .7 .4
(400) (18) (9)
16.7 .9 .47
(425) (23) (12)
Weight
Lbs. (kg)
11
(5)
17.9
(8.1)
40.8
(18.5)
77.2
(35)
127.8
(58)
321.9
(146)
550.7
(250)
