Keypad Control Menu (M2)
In the Keypad Control Menu, you can set the frequency reference, choose the motor
direction for keypad operation, and determine if the STOP button will be active at all
times. See Figure 6-5.
Speed
Setpoint
Keypad
Direction
Stop Button
Active
PI Setpoint
PI Setpoint
Default
LIT-1201828

Figure 6-5: Keypad Control Menu

R2.1 Range: 0 — Max. Frequency
Units: %
Speed Setpoint
This displays and allows the operator to edit the keypad speed setpoint. A change
takes place immediately. This reference value will not influence the output
frequency unless the keypad has been selected as the active control place.
P2.2 Range: Forward, Reverse
Keypad Direction
This allows the operator to change the rotation direction of the motor. This setting
will not influence the rotation direction of the motor unless the keypad has been
selected as the active control place.
P2.3 Range: Yes, No
StopButtonActive
By default, pushing the STOP button will always stop the motor regardless of the
selected control place. If this parameter is set to No, the STOP button will stop the
motor only when the keypad has been selected as the active control place. The
Start Command must be toggled or re-issued to restart the drive.
R2.4 Range: Application Dependent
PI Setpoint
PI regulators setpoint. Parameter not available in Remote Input Application.
P2.5 Range: Application Dependent
PI StPt Default
PI regulators default setpoint. This parameter is set in Start-Up Wizard. Parameter
not available in Remote Input Application.
For more information visit: www.johnsoncontrols.com

M2 Keypad Control

R2.1 Speed Setpoint

P2.2 Keypad Direction

. . .

P2.5 PI-StPt Default

VSD Series Drives User Manual
Default: Forward
Default: Yes
Default: Application
Dependent
Default: Application
Dependent
6-7
