Keypad Control Parameters — M2
This menu provides the parameters for the setting of the keypad speed setpoint, the selection
of motor direction when in keypad operation, and when the STOP button is active.
Table 13-12: Keypad Control Parameters — M2
Code Parameter
R2.1 Speed Setpoint
P2.2 Keypad Direction 0
P2.3 StopButton
Active
R2.4 PI-Setpoint
P2.5 PI-Setpoint
Default
Keypad Control Parameter ID Numbers are listed separately on Page 15-28.
Menus — M3 to M6
Menus M3 to M6 provide information on the Active Faults, Fault History, System Menu
settings and the Expander Board setup. These menu items are explained in detail in
Chapter 6.
LIT-1201828
Min. Max.
0.0 100.0
1
0 1
(-10000) (10000)
(-10000) (10000)
For more information visit: www.johnsoncontrols.com
ID
Number
Unit Default
% 0.0
0 1009
1 1110
(50)
1011
VSD Series Drives User Manual
Description
Keypad Speed Setpoint.
Reverse request active from the
panel
0 = Forward
1 = Reverse
Stop button (Keypad) always
active (Yes/No)
PI-regulators default setpoint
13-17
