Table 10-3: Input Signals — M1 ➔ G1.2, continued
Code Parameter
P1.2.8 (A) DI-5 Funct.
P1.2.9 (A) DI-6 Funct.
P1.2.10 (A) AI-1 Minimum 0.00
P1.2.11 (A) AI-1 Maximum Min.
P1.2.12 (A) AI-1 Invert
P1.2.13 (A) AI-1 Filter
P1.2.14 (A) AI-2 Minimum 0.00
LIT-1201828
Min. Max.
0 17
0 17
Max.
100.0
0 1
0.00 10.00
Max.
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
9 207
0 208
% 0.00 217
% 100.00 218
0 209
s 0.10 210
% 20.00 219
VSD Series Drives User Manual
Default #9 Fire-Mode
0 = Not Used
1 = Ext. fault, closing contact
2 = External fault, opening contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
Default #0 Overload Fault
Relay-input
0 = Overload fault relay (Used in
Intellipass)
1 = Ext. fault, closing contact
2 = External fault, opening contact
3 = Fault reset
4 = Run enable-Closed Contact
5 = Force ctrl. place to Hand
6 = Force ctrl. place to Auto
7 = Reverse
8 = Speed Select 1
9 = Fire Mode-Closed Contact
10 = Speed Select 2
11 = Speed Select 3
12 = Force Bypass
13 = External interlock closed
14 = External interlock open
15 = Mot. Pot. UP
16 = Mot. Pot. DOWN
17 = Fire Mode-Open Contact
Default applies for 0V or 0 mA
Default applies for 10V or 20 mA
0 = Not inverted
1 = Inverted
0 = No filtering
Default applies for 2V or 4 mA
10-7
