November 2009

Table 5-2: VSD Series Enclosed Drives Selection Chart

Base Product
Horsepower (VT)
Voltage
Enclosure Rating
Enclosure Style
Revision Number
Separator (–)
Communications
Option 1
Option 2
All horsepower ratings are Variable Torque (VT).
1 to 60 hp @ 208V; 1 to 75 hp @ 230V; 1 to 150 hp @ 480V; 3 to 100 hp @ 575V
N2/XT/SA Communications selectable on drive keypad.
SA = Sensor Actuator Bus for FEC Interface.

Table 5-3: Options List

Option
00
P3
P6
P9
SA
IntelliPass only.

Table 5-4: Option Notes

All VSD Series IntelliPass Drives incorporate two factory-installed Auxiliary Contacts
(formerly the K9 option).
P3
P9
SA
LIT-1201828
Code Number
VS = Variable Speed Drive
Prefix
001 = 1.0 hp to
150 = 150 hp
1 = 208V
2 = 230V
4 = 480V
5 = 575V
1 = TYPE 1
2 = TYPE 12
3 = TYPE 3R
2 = Enclosed IntelliPass
3 = Enclosed Drive w/Disconnect (IntelliDisconnect)
A = Rev 1 (Americas)
0 = None
N = N2/XT/SA Bus Comm (N2 by default)
L = L W
ON ORKS
See Options List
See Options List
Description
None
Line Fuses (formerly Drive Isolation Fusing) — Provides high-level fault protection of the
input power circuit from the load side of the fuses to the input side of the power transistors.
The option consists of three 200 kA fuses, which are factory mounted in the enclosure.
Third Contactor Drive Isolation — Provides load side isolation to the drive in the event of an
SCR or DC Bus failure, allowing the drive to go into bypass without tripping the circuit
breaker. Typically used in critical applications or when required in a specification.
Line Fuses & Third Contactor
Space Heater w/Transformer — Prevents condensation from forming in the enclosure when
the drive is inactive or in storage. Includes a thermostat for variable temperature control.
Line Fuses Line Fuses, on load side of breaker in both drive and bypass modes
Always included in the part number for 575V Enclosed IntelliPass Drives
Line Fuses & Mutually exclusive from Option P3 (Line Fuses) in 575V Enclosed
Third Contactor IntelliPass Drives
Space Heater Only available for TYPE 3R (Enclosure Rating 3).
w/Transformer
For more information visit: www.johnsoncontrols.com
V S
Network
®
VSD Series Drives User Manual
-
5-3
