Appendix A — Technical Data
Specifications
Table A-1: VSD Series Drive Specifications
Description
Power Connections
Input Voltage (V
Input Frequency (f
Connection to Utility Power
High Interrupt Rating
Motor Connections
Output Voltage
Continuous Output Current
Starting Torque
Output Frequency
Frequency Resolution
Control Characteristics
Control Method
Switching Frequency
Frequency Reference
Field Weakening Point
Acceleration Time
Deceleration Time
Braking Torque
Environment
Ambient Operating
Temperature
Storage Temperature
Relative Humidity
Air Quality
Altitude
LIT-1201828
Specification
) 230V +10%/-15%
in
480V +10%/-15%
575V +10%/-15%
) 50/60 Hz (variation up to 45 – 66 Hz)
in
Once per minute or less (typical operation)
The current withstand rating of the drive is 100,000 Amperes
When Freedom Starters and an HMCP, the current interrupting rating is
100,000 Amperes
When used with IT. style starters, the current interrupting rating is
36,000 Amperes
0 to V
in
Ambient temperature max. +104°F (+40°C), overload 1.1 x I
(1 min./10 min.)
110%
0 to 320 Hz
0.01 Hz
Frequency Control (V/f)
Open Loop Sensorless Vector Control
Adjustable with Switching Frequency
230V: 1 – 20 hp: 1 to 16 kHz; default 3.6 kHz
25 – 40 hp: 1 to 10 kHz; default 3.6 kHz
480V: 1 – 40 hp: 1 to 16 kHz; default 3.6 kHz
50 – 250 hp: 1 to 10 kHz; default 3.6 kHz
575V: All hp: 1 to 6 kHz; default 1.5 kHz
Analog Input: Resolution 0.1% (10-bit), accuracy ±1%
Panel Reference: Resolution 0.01 Hz
30 to 320 Hz
0.1 to 3000 sec.
0.1 to 3000 sec.
DC brake: 15% to 150% x T
14°F (-10°C), no frost to 104°F (+40°C)
-40°F (-40°C) to 158°F (70°C)
0 to 95% RH, noncondensing, non-corrosive, no dripping water
Chemical vapors: IEC 60721-3-3, unit in operation, class 3C2
Mechanical particles: IEC 60721-3-3, unit in operation, class 3S2
100% load capacity (no derating) up to 3300 ft. (1000m); 1% derating for
each 330 ft. (100m) above 3300 ft. (1000m); max. 10000 ft. (3000m)
For more information visit: www.johnsoncontrols.com
VSD Series Drives User Manual
(without brake option)
n
L
A-1
