Protections — M1 ➔ G1.7
Table 12-8: Protections — M1 ➔ G1.7
Code Parameter
P1.7.1 Input Phase
Supv
P1.7.2 4mA Fault Resp
P1.7.3 Ext. Fault Resp
P1.7.4 FBComm.
FaultResp
P1.7.5 SlotComFault
Resp
P1.7.6 Motor Therm
Prot
P1.7.7 MotAmbTemp
Factor
P1.7.8 MTP f0 Current
P1.7.9 MTP Motor T
P1.7.10 Motor Duty
Cycle
P1.7.11 Stall Protection
P1.7.12 Stall Current
P1.7.13 Stall Time Lim
P1.7.14 Stall Freq Lim
LIT-1201828
Min. Max.
0 2
0 2
0 2
0 2
0 2
0 3
-100.0 100.0
0.0 150.00
1 200
0 100
0 3
0.00 Motor
CurrentMax
1.00 120.00
1.00 Max_Freq
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
2 701
0 702
2 703
0 704
0 705
0 707
% 0.0 708
% 40.0 709
min 45 710
% 100 711
0 712
A 1.00 713
s 15.00 714
Hz 25.00 715
VSD Series Drives User Manual
Response to input phase
supervision.
0 = No Action
1 = Warning
2 = Fault
Response to 4 mA signal
supervision.
0 = No Action
1 = Warning
2 = Fault
Response to external fault digital
input signal supervision.
0 = No Action
1 = Warning
2 = Fault
Response to fieldbus
communication supervision.
0 = No Action
1 = Warning
2 = Fault
Response to slot communication
supervision.
0 = No Action
1 = Warning
2 = Fault
0 = No response
1 = Warning
2 = Fault, stop mode after fault
according to ID402
3 = Fault, stop mode after fault
always by coasting
Percent of ambient temperature.
Percent of motor nameplate
current.
Time to reach 63% of final value.
Percent of nominal motor load
0 = No response
1 = Warning
2 = Fault, stop mode after fault
according to ID402
3 = Fault, stop mode after fault
always by coasting
12-13
