November 2009
H6
W5
W3
W5
D1

Figure A-12: VSD Series Open Drive Dimensions, OPEN 1 and OPEN 12 FR9

Table A-12: Dimensions for VSD Series Open Drive, FR9

Frame
Size Voltage hp (VT)
FR9 230V 100
480V 200 – 250
575V 125 – 200

Table A-12: Dimensions for VSD Series Open Drive, FR9, continued

Frame
Size Voltage
FR9 230V
480V
575V
Brake resistor terminal box (H6) included when brake chopper ordered.
LIT-1201828
H4
H2
H1
Approximate Dimensions in Inches (mm)
W1 W2
18.9 15.7
(480) (400)
Approximate Dimensions in Inches (mm)
hp (VT) H5 H6
100 .6 7.4
(16) (188)
200 – 250
125 – 200
For more information visit: www.johnsoncontrols.com
H3
W4
W2
H5
Dia.
D2
W3 W4 W5
6.5 .4 2.1
(165) (9) (54)
D1 D2 D3
14.3 12.9 11.2
(362) (327) (285)
VSD Series Drives User Manual
D3
N1
H1 H2 H3
45.3 44.2 28.3
(1152) (1122) (721)
Knockouts @
Inches (mm)
Dia. N1 (O.D.)
.8 4 @ 2.32
(21) (59)
W1
H4
8.0
(205)
A-13
