- Page 1 Variable Speed Drive Series II LIT-12012316 JCI VSD Series II Installation Manual Addendum New control board update 525-600V offering Effective May 2017...
- Page 2 The maximum liability of this warranty is limited to the purchase price of the product. In no event, regard- less of cause, shall Johnson Controls Inc. or Eaton Electrical Inc. be liable (a) for penalties or penalty clauses of any description, or (b) for certification not otherwise specifically provided herein and/or indem-...
- Page 3 Effective May 2017 Support Services The goal of Johnson Controls is to ensure your greatest possible satisfaction with the operation of our products. We are dedicated to providing fast, friendly, and accurate assistance. Whether it’s by phone, fax, or e-mail, you can access support information listed below You should contact your local Johnson Controls Sales representative for product pricing, availability, or- dering, expediting, and repairs.
-
Page 4: Table Of Contents
LIT-12012316 Series II Installation Manual Addendum Effective May 2017 Table of Contents Manual Addendum.................................. 4 New Control Board Installation Requirements......................... 5 Control Board............................5 LED Status Indication ..........................6 Control Board Terminals ........................... 6 Control Wiring............................6 DIP Switch Functionality ........................... 7 Digital input ground isolation ........................ -
Page 5: New Control Board Installation Requirements
Series II Installation Manual Addendum LIT-12012316 Effective May 2017 New Control Board Installation Requirements The new control board launched to provide additional capabilities to the Series II product including LED indication, dip switch operation and improved processing power. There is a change in the control terminal landing locations, the battery for the real time clock and dip switch functionality. -
Page 6: Led Status Indication
LIT-12012316 Series II Installation Manual Addendum Effective May 2017 LED Status Indication The status LED of the drive shows the status of the drive. The status LED is located in the control panel, below the keypad, and it can show 5 different statuses Color of the LED light Status of the drive Blinking slowly... -
Page 7: Dip Switch Functionality
Series II Installation Manual Addendum LIT-12012316 Effective May 2017 DIP Switch Functionality You can make 2 selections with the DIP switches for specified terminals. The switches have 2 positions: up and down. You can see the location of the DIP switches and the possible selections below. A. -
Page 8: Digital Input Ground Isolation
LIT-12012316 Series II Installation Manual Addendum Effective May 2017 Digital input ground isolation It is possible to isolate from ground the digital inputs (terminals 8-10 and 14-16) on the standard I/O board. To do this, change the position of a DIP switch on the control board. A. -
Page 9: Control Board Cabling
Series II Installation Manual Addendum LIT-12012316 Effective May 2017 Control Board Cabling The standard I/O board has 22 fixed control terminals and 8 relay board terminals. Selection of the Control Cables The control cables must be a minimum of 0.5 mm screened multicore cables. -
Page 10: Series Ii Series Overview - 525-600V
LIT-12012316 Series II Installation Manual Addendum Effective May 2017 Series II Series Overview - 525-600V Catalog Number Selection SERIES II Series Open Drives Notes All boards are varnished (conformed coated). Corrosion resistant. Battery included in all drives for real-time clock. Three year lifetime. Keypad kit includes HOA bypass. -
Page 11: Power Ratings And Product Selection
Series II Installation Manual Addendum LIT-12012316 Effective May 2017 Power Ratings and Product Selection Series II Series Drives – 525-600V NEMA Type 1/IP21 or NEMA Type 12/IP54 Drive Rated Current and hp De-Rated _ Can Be: Drive Rating Low Overload Full Drives Low Overload 1 = N1 = IP21... -
Page 12: Mounting Drive Dimensions
LIT-12012316 Series II Installation Manual Addendum Effective May 2017 Mounting Drive Dimensions NEMA Type 1/12 Open Drives (1-200hp) Approximate Dimensions in Inches (mm) Frame Line Weight Size Voltage hp (VT) Amperes in Lbs 600 Vac 3-10 3.9-11 8.73 16.5 15.98 15.04 5.67 4.53... -
Page 13: Series Ii Technical Data
Variable Speed Drive Series II LIT-12012316 Series II Technical Data Description Attribute Specification Mains connection Input voltage U 525-600V, -10 to 10% Input frequency 50-60 Hz, -5 to 10% Connection to mains Once per minute or less Starting delay 6s (FS5 to FS6); 8s (FS7 to FS9) Motor connection Output voltage 0-Uin... - Page 14 LIT-12012316 Series II Installation Manual Addendum Effective May 2017 Series II Technical Data, continued Attribute Description Specification EMC (at default Immunity Fulfils EN61800-3 (2004), first and second environment settings) EN61800-3 (2004), Category C3 Emissions The drive can be modified for IT-networks Noise level Average noise level FS5: 65...
-
Page 15: Cable Power And Motor Wiring Guidelines
Series II Installation Manual Addendum LIT-12012316 Effective May 2017 Cable Power and Motor Wiring Guidelines Fuse NEC Wire Size Terminal Connection Size I(L) I(L) Rating (AWG) (AWG) Suf- Amps Amps (Class Line and Line and Mo- Frame at 40°C at 50°C Motor Ground Ground... - Page 16 LIT-12012316 Series II Installation Manual Addendum Effective May 2017 ©2017 Johnson Controls All Rights Reserved Printed in USA Building Technologies & Solutions Publication No. LIT-12012316 507 E. Michigan Street May 2017 P.O. Box 423 Milwaukee, WI 53201 www.johnsoncontrols.com...
