Table 10-13: Monitoring Menu, continued
Code Parameter
V7.9 DC-Bus Voltage
V7.10 Unit
Temperature
V7.11 Motor
Temperature
V7.12 (A) AI-1
V7.13 (A) AI-2
V7.14 DI-1 DI-2 DI-3
V7.15 DI-4 DI-5 DI-6
V7.16 DO-1 RO-1 RO-2
V7.17 (A) AO-1
V7.18 ActFaultCode
V7.19 ActWarnCode
V7.20 Status Word
V7.21 PI-Setpoint
V7.22 PI-Input
V7.23 PI-Error
V7.24 PI-Output
V7.25 RO-1 RO-2 RO-3
G7.26 Multimonitor
When OPTB5 is not installed in option slot C, this in not displayed.
Operate Menu — M8
The Operate Menu provides an easy to use method of viewing key numerical Monitoring
Menu items. It also allows the setting of the keypad frequency reference. See Chapter 6 for
more information.
10-18
Min. Max.
0 1000
-1000 1000
0.0 1000.0
-10.00 20.00
-10.00 20.00
0 7
0 7
0 7
0.00 20.00
0 200
0 200
-32768 32767
0.0 100.0
0.0 100.0
0.0 100.0
0.0 100.0
0 7
— —
For more information visit: www.johnsoncontrols.com
ID
Unit Default Number Description
V 0 9
°F 0 10
% 0.0 11
V 0.00 12
mA 0.00 13
0 14
0 15
0 16
mA 0.00 17
0 18
0 19
0 20
% 0.0 21
% 0.0 22
% 0.0 23
% 0.0 24
0 25
— —
Eaton Technology
Powered by
November 2009
[R] DC voltage in Volts Tfilt =
32ms.
Temperature of the heat sink
Voltage Input value [V]
Current Input value [mA]
DIA-1, DIA-2 and DIA-3 status
DIB-4, DIB-5 and DIB-6 status
DO-1, RO-1 and RO-2 status
Active Fault code.
Active Warning code.
b0 = Drive Ready
b1 = Run Enable
b2 = Drive Running
b3 = Drive Reversing
b4 = General Fault
b5 = General Warning
b6 = Preset Speed Active
b7 = Motor Regulator Active
b8 = Output speed supervision
indication
b9 = Setpoint speed supervision
indication
b10 = HAND Control indication
b11 = AUTO Control indication
b12 = D-IN Firemode
b13 = Damper control signal
b14 = Bypass mode status
indication
b15 = Bypass running
Actual Sensor Value
Monitoring the OPTB5 relay
outputs.
Displays three monitor values
simultaneously
