Chapter 15 — Description of Parameters
Parameters by ID Number
On the following pages you will find the parameter descriptions arranged according to the
individual ID number of the parameter.
101 Minimum frequency
102 Maximum frequency
Defines the frequency limits of the drive. The maximum value for these parameters is
320 Hz. The software will automatically check the value of parameter ID314.
103 Acceleration time 1
104 Deceleration time 1
These limits correspond to the time required for the output frequency to accelerate
from the zero frequency to the set maximum frequency (parameter ID102).
105 Nominal voltage of the motor
Find this value V
weakening point (ID604) to 100% * V
106 Nominal frequency of the
motor
Find this value f
point (ID604) to the same value.
107 Current limit
This parameter determines the maximum motor current from the drive. The
parameter value range differs for each power rating.
108 Nominal current of the motor
Find this value l
109 Motor Power Factor
Find this value "Power Factor" on the motor nameplate.
110 Service Factor
This will calculate motor current limit current limit.
Current Limit = Service Factor (SF) x Motor nominal current ID108.
111 Nominal speed of the motor
Find this value n
LIT-1201828
on the motor nameplate. This parameter sets the voltage at the field
n
nMotor
on the motor nameplate. This parameter sets the field weakening
n
on the motor nameplate.
n
on the motor nameplate.
n
